Associated Numbers
428000-6770 UD16989S CST40394AS 3258 DRS1137 DS2247 DSN1364 S-80606 25-5126 SG1074 STN6770 254636D AH42-11001-BB LR011262 LR016450 LR16450 LRS03963 450.529.102 20432493BN STM316 6040394.0 19178N 91-29-587 STR70351 4280006770 Denso 450529102 AH4211001BB SND0792 AH42-11001BB Lester 19178 30362 PIC Picture ID 190-6227 428000-677 Substitutes: J&N 410-52579Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 190 mm |
Mount Hole Center - Center (O.1) | 142 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 62 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LAND ROVER | Discovery 5.0 V8 4x4 | 09.2009- | |
LAND ROVER | Range Rover 5.0 4x4 | 09.2009-08.2012 | |
LAND ROVER | Range Rover Sport 5.0 4x4 | 04.2009-03.2013 | |
LAND ROVER | Range Rover Sport 5.0 4x4 | 07.2009-03.2013 | |
LAND ROVER | Range Rover Sport 5.0 4x4 | 09.2009-03.2013 |
Reference Information
LRS3963 CST40394AS 254636D STN6770 STR6302 450.529.102 LRS03963 25-5126 S-80606 UD16989S DSN1364 3258 LR16450 91-29-587 DS2247 STRE255 STM316 LR016450 LR011262 SG1074 19178N 336067 6040394 20432493BN DRS1137 428000-6770 AH42-11001-BB STR70351Video/Publications
19178N 20432493BN 25-5126 254636D 3258 428000-6770 450.529.102 6040394.0 91-29-587 AH42-11001-BB CST40394AS DRS1137 DS2247 DSN1364 LR011262 LR016450 LR16450 LRS03963 LRS3963 S-80606 SG1074 STM316 STN6770 STR70351 STRE255 UD16989SAdd Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
