Associated Numbers
128000-9860 28100-64130 JS902 UD16991S CST44118AS DRS3483 DS4593 11380 8EA732678-001 20902 944280522940 MRS52294 20452811BN 6044118.0 28100-64200 STR70042Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 188 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 3 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Carina 2.0 D | [2C] | 01.1993-01.1996 |
| TOYOTA | Carina 2.0 D | [2C] | 04.1992-01.1996 |
| TOYOTA | Carina 2.0 D | [2C] | 08.1992-01.1996 |
| TOYOTA | Corolla 2.0 D | [2C] | 07.1992-04.1997 |
Reference Information
28100-64200 11380 9.44281E+11 UD16991S STR6261 STR70042 DS4593 MRS52294 ANM15703X DRS3483 3T346 20452811BN MTT346 3T222 2810064341 2810064340 20902 JS902 8EA732678-001 MTT222 6044118 003-T346 STRS965 CST44118AS 003-T222 MAV461180 128000-9860 28100-64130Video/Publications
003-T222 003-T346 11380 128000-9860 20452811BN 20902 28100-64130 28100-64200 3T222 3T346 6044118.0 8EA732678-001 944280522940 CST44118AS DRS3483 DS4593 JS902 MAV461180 MRS52294 MTT222 MTT346 STR70042 STRS965 UD16991SAdd Your Number
