Associated Numbers
DSN2067 UD810204(DENSO)S CST40435AS 228080-4374 S-8929 246-14151 STN0669 20669 190.941.092 20432534BN 6040245.0 6040435.1 28300-22002-71 28300-22003-71 DENDSN2067Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 188 mm |
Mount Hole Center - Center (O.1) | 115 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 20 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Wet Clutch | Yes |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Hilux 2.4 i 4WD | [22RE] | 01.1989-07.1997 |
TOYOTA | Land Cruiser 2.4 | [22R] | 11.1984-05.1993 |
TOYOTA | Land Cruiser 2.4 | [22RE] | 12.1988-12.1996 |
Reference Information
2810034044 28100U210071 28100-34053 28100-34052 CST40435AS 2810034040 UD810204(DENSO)S 2810034042 2810034043 STN0669 28100U2100 6040245 228080-4374 2810020571 2810020572 28100-22000 28300-22002-71 28100-20550-71 2810035060 190.941.092 2810020557 2810035040 2.81002E+11 28100-34042 28100-34044 2810035020 28100-34043 2810034052 2810035140 2810034053 2810008020 28100-20572 6040435.1 20669 DENDSN2067 28300-22003-71 2810022000 20432534BN 246-14151 DSN2067 S-8929 2830022003Video/Publications
190.941.092 20432534BN 20669 228080-4374 246-14151 28300-22002-71 28300-22003-71 6040245.0 6040435.1 CST40435AS DENDSN2067 S-8929 STN0669 UD810204(DENSO)SAdd Your Number
