Associated Numbers
DSN2085 UD810219(DENSO)S CST40181AS CST40181GS DENDSN2085 228080-1041 S-8924 246-14128 1738163013 1920263011 1982163011 20896 20896D 690.552.112 20432181BN 20432181OE 6040181.0 6040181.1Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 188 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 25.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KUBOTA | Engine | [V2202] | 01.1992- |
Reference Information
20896 110940 228000-1040 228000-1041 18141N 6040181.1 690.552.112.785 6040181 690.552.112.261 1562163015 690.552.112.781 1562163014 690.552.112.780 LRS01547 1562163011 1562163010 15425-63016 9722809100 15621-63011 20432181BN 15621-63010 15621-63013 15621-63012 15621-63015 15621-63014 17381-63015 20432181OE 1560163010 25-3036 CST40181GS 17381-63014 17381-63013 15601-63012 15601-63010 15601-63011 UD810219(DENSO)S 70000-73490 1560163011 1560163012 19013-63012 STR6124 19013-63011 LRS1547 20896D 335747 CGB-8924 DENDSN2085 690.552.112.415 DSN2085 CST40181AS STR70490 690.552.112.050Video/Publications
UD810219(DENSO)S CGB-8924 18141N LRS1547 LRS01547 19013-63012 17381-63013 228000-1041 228000-1040 25-3036 DSN2085 6040181.1 6040181.0 20432181OE 20432181BN CST40181GS CST40181AS 690.552.112.415 690.552.112.781 690.552.112.785 690.552.112.780 690.552.112.261 690.552.112.050 20896D 17381-63015 DENDSN2085 STR70490 110940Add Your Number
