Associated Numbers
17672N 17672R 20432152BN 228000-4080 228000-4081 228000-4082 228000-4083 28100-52030 28100-62030 6040251.0 88213648 91-29-5291 91-29-5291N 9622809-408 CST40251AS S-8457 STN3173 STR70181 UD17000SSpecifications
Kilowatt | 1.8 kW |
Length (L.1) | 210 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 17.5 mm |
Rotation | CW |
Spigot Diameter (A) | 55 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | 4 Runner 3.4 | 01.1996-12.2002 | |
TOYOTA | T100 3.4 | 12.1995-12.1998 | |
TOYOTA | Tacoma 3.4 | 01.1995-12.2004 | |
TOYOTA | Tundra 3.4 | 01.2000-12.2004 |
Reference Information
20432152BN 91-29-5291N 28100-52030 S-8457 228000-4080 91-29-5291 CST40251AS 228000-4082 228000-4081 9622809-408 6040251 228000-4083 STR70181 STN3173 17672R 88213648 28100-62030 17672N UD17000SVideo/Publications
17672N 17672R 20432152BN 228000-4080 228000-4081 228000-4082 228000-4083 28100-52030 28100-62030 6040251.0 88213648 91-29-5291 91-29-5291N 9622809-408 CST40251AS S-8457 STN3173 STR70181 UD17000SAdd Your Number
