Associated Numbers
113665 190.546.092 20452011BN 228000-4020 228000-4310 228000-6730 228000-6750 25-2218 28100-0E010 28100-11060 28100-11080 28100-11140 28100-11160 6044110.0 91-29-5489 CST44110AS JS1023 LRT00212 S-8907 STN1023 UD90021S 17679N DXS463 SRJ155 16967 16-967Specifications
Kilowatt | 0.8 kW |
Length (L.1) | 202 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 5.5 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Corolla 1.3 16V XLi | [4E-FE] | 07.1992-09.1995 |
TOYOTA | Corolla 1.3 XLi | [4E-FE] | 07.1992-04.1997 |
TOYOTA | Corolla 1.3 XLi | [4E-FE] | 09.1995-04.1997 |
TOYOTA | Corolla 1.4 | [4E-FE] | 04.1997-02.2000 |
TOYOTA | Corolla 1.4 16V GLi | [4E-FE] | 07.1992-09.1995 |
TOYOTA | Corolla 1.4 16V XLi | [4E-FE] | 07.1992-09.1995 |
TOYOTA | Paseo 1.5 | [5E-FE] | 01.1996-01.1997 |
TOYOTA | Paseo 1.5 | [5E-FE] | 01.1997-01.1997 |
TOYOTA | Paseo 1.5 | [5E-FE] | 01.1998-01.1998 |
TOYOTA | Paseo 1.5 | [5E-FE] | 01.1999-01.1999 |
TOYOTA | Paseo 1.5 16V | [5E-FE] | 08.1995-07.1999 |
TOYOTA | Paseo 1.5 16V | [5E-FE] | 10.1996-01.1998 |
TOYOTA | Starlet 1.3 | [4E-FE] | 04.1996-03.1999 |
TOYOTA | Tercel 1.5 CE | [5E-FE] | 01.1997-01.1997 |
TOYOTA | Tercel 1.5 CE | [5E-FE] | 01.1998-01.1998 |
Reference Information
UD90021S MAV461100 JS1023 228000-6730 228000-4310 CST44110AS 20452011BN 228000-6750 25-2218 STR6667 190.546.092 S6321S 17679N 28100-11060 113665 28100-11160 91-29-5489 28100-11140 28100-11080 LRT00212 STN1023 S-8907 J5212088 228000-4020 6044110 STRW426 28100-0E010Video/Publications
113665 17679N 190.546.092 20452011BN 228000-4020 228000-4310 228000-6730 228000-6750 25-2218 28100-0E010 28100-11060 28100-11080 28100-11140 28100-11160 6044110.0 91-29-5489 CST44110AS J5212088 JS1023 LRT00212 MAV461100 S-8907 STN1023 STRW426 UD90021SAdd Your Number
