S6320S - Brand new AS-PL Starter motor

Name: Brand new AS-PL Starter motor
Brand: AS-PL
SKU: S6320S
Price: 415.07 NZD
Availability: InStock

Brand new AS-PL Starter motor

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

DENSO

Price:

NZ$ 415.07 including GST

NZ$ 360.93 excluding GST

UOM:

each

Product Code:

S6320S

Quantity In Stock:

Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications
Add Your Number

113312 17671N 190.564.092 228000-5290 228000-5292 228000-5293 25-3239 256265 28100-62040 88213153 DRS0587 DS1697 J5212103 LRS01691 STN1231 STR70134 UD16849S snj227 srj160 dxs533 dxs468 ACDelco 323-1031 AIM 17125R ST-0079R Amsco VS-17125 Arrowhead SND0105 Ashdown Ingram DXS468 BBB Industries 17125 Bosch Reman SR117X Service Europe 0-986-UR1-012 Delco DRS3648 DENSO 128000-536 128000-5360 128000-5361 128000-556 128000-5560 128000-5561 128000-557 128000-5570 128000-5571 128000-577 128000-5770 128000-656 128000-6560 128000-6561 Auto Parts 280-0103 280-0116 Denso 9712809-556 Dixie Electric Ltd S-8226 Dynamic DS17125 HC CARGO 111551 IAT 610-17125 Industry J&N 410-52476 Lester Old 17488 Lucas (Europe) LRS01247 LRS01252 S9727 MPA 12097 NAPA 244-6504 44-6500 44-6501 44-6504 44-6505 44-6506 PIC 190-226 RELIANCE 61894 Remy 16892 Romaine 41-17125 Standard Starter Drive 432218 Toyota 28100-0W030 28100-65020 28100-65020-84 28100-65030 28100-65030-84 USA S1537 Voltux V1-17125 WAI 17125N 2-1060-ND Whatcom 22626 Wilson 91-29-5182 Unipoint STR-8082 ARROWHEAD SND0273 BOSCH 128000-9790 228000-1150 280-0271 ELECTRICAL PRODUCTS 410-52440 LESTER 17487 LUCAS ELECTRIC LRS1252 TOYOTA 28100-0W020

Kilowatt	1.2 kW
Length (L.1)	188 mm
Mount Hole Center - Center (O.1)	105 mm
Mount Hole Diameter (C.1)	M10x1.25 mm
Mount Hole Diameter (C.2)	M10x1.25 mm
No./Mount holes	2 qty
No./Mount holes with thread	2 qty
No./Teeth	9 qty
Pinion at Rest (B)	17 mm
Rotation	CW
Spigot Diameter (A)	55 mm
Unit Type	DENSO
Voltage	12 V

Make	Model	Type	Year
TOYOTA	4-Runner 3.4	[5VZ-FE]	01.1995-12.2002
TOYOTA	Land Cruiser 3.4 V6	[5VZ-FE]	01.1996-

88213153 DS1697 190.564.092 LRS1691 113312 256265 228000-5292 J5212103 STN1231 228000-5290 DRS0587 25-3239 228000-5293 LRS01691 UD16849S 17671N 28100-62040 STR70134

113312 17671N 190.564.092 228000-5290 228000-5292 228000-5293 25-3239 256265 28100-62040 88213153 DRS0587 DS1697 J5212103 LRS01691 LRS1691 STN1231 STR70134 UD16849S
