Associated Numbers
31200R9GJ01 428000-8930 PYDR2 STN8930 STN8930BA UD14267SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 205 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 10 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 33 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | N-Box 0.66 | 01.2011-12.2014 | |
HONDA | N-One 0.66 | 01.2011-12.2014 |
Reference Information
428000-8930 STN8930BA STN8930 PYDR2 31200R9GJ01 UD14267SVideo/Publications
31200R9GJ01 428000-8930 PYDR2 STN8930 STN8930BA UD14267SAdd Your Number
