Associated Numbers
190.949.092 19257N 428000-0551 428000-1260 428000-1261 STN3190 STR70493 UD02916S 2280008000 2280008001 1906394 PIC 190949092 PSH 19257 Lester 2810073020 Toyota 2810075190 4280000551 Denso show 4280001260 4280001261 4280001261SEL +line STR6421sa Electrolog dxs4040 DXS4031 70-8446-1NP 70-8446-1R snj265 4280801263 4280801262 4280801261 28100-75191 4280001262 4280001263 2810075151 2280008002Specifications
| Kilowatt | 1.6 kW |
| Length (L.1) | 193 mm |
| Mount Hole Center - Center (O.1) | 104 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 20 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Hilux 2.7 | 01.2004-12.2009 | |
| TOYOTA | Land Cruiser Prado 2.7 | 01.2003-12.2009 |
Reference Information
UD02916S 28100-75190 28100-75191 190.949.092 28100-73021 S6311S STM3190 28100-73020 428000-1261 428000-1260 STR6421 428000-0551 19257N STR70493 STN3190Video/Publications
190.949.092 19257N 28100-73020 28100-73021 28100-75190 428000-0551 428000-1260 428000-1261 STM3190 STN3190 STR70493 UD02916SAdd Your Number
