Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 339.32 including GST
NZ$ 295.06 excluding GST
or four payments of $84.83
with
Learn More
each
S6036.
S6309S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
228000-8540Associated Numbers
113314 17805R 201233 201233D 20452101 228000-8540 228000-8542 25-2422 28100-21020 2810021020 2810021021 2810021022 6044101 8EA737971-001 91-29-5496N 9709 CST44101 CST44101AS CST44101ES CST44101GS CST44101OS CST44101RS DRS3866 DSN934 F042S00207 J5212104 LRS01479 STN1224 UD20534S
S6036 S6256S S6036
Specifications
| Kilowatt | 0.80 kW |
| Length (L.1) | 200.50 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 14 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Corolla 1.5 RC | [1NZ-FE] | 06.2004- |
| TOYOTA | Echo 1.5 | [1NZ-FE] | 01.2004- |
| TOYOTA | Echo 1.5 VVTi | [1NZ-FE] | 04.1999-08.2005 |
| TOYOTA | Echo 1.5 VVTi | [1NZ-FE] | 04.2003-08.2005 |
| TOYOTA | Opa 1.8 | [1ZZ-FE] | 04.2000-08.2003 |
| TOYOTA | Premio 2.0 | [1AZ-FSE] | 12.2001-06.2007 |
| TOYOTA | Yaris 1.3 16V | [2NZ-FE] | 11.1999- |
| TOYOTA | Yaris 1.5 | [1NZ-FE] | 03.2006- |
| TOYOTA | Yaris 1.5 i | [1NZ-FE] | 04.2001- |
| TOYOTA | Yaris 1.5 TS | [1NZ-FE] | 01.2003- |
| TOYOTA | Yaris 1.5 VVTi TS | [1NZ-FE] | 03.2003-07.2005 |
| TOYOTA | Yaris Verso 1.3 | [2NZ-FE] | 08.1999-10.2002 |
| TOYOTA | Yaris Verso 1.3 | [2NZ-FE] | 11.2002- |
| TOYOTA | Yaris Verso 1.3 VVTi | [2NZ-FE] | 03.2000-09.2005 |
| TOYOTA | Yaris Verso 1.5 | [1NZ-FE] | 03.2000- |
| TOYOTA | Yaris Verso 1.5 | [1NZ-FE] | 03.2000-09.2005 |
| TOYOTA | Yaris Verso 1.5 TS | [1NZ-FE] | 05.2003- |
| TOYOTA | Yaris Verso 1.5 VVTi | [1NZ-FE] | 03.2000-03.2003 |
Reference Information
| 003-T356 | ASHIKA |
| 003-T376 | ASHIKA |
| 113314 | CARGO |
| 17805R | WAI / TRANSPO |
| 190.558.092.050 | PSH |
| 201233 | KUHNER |
| 201233D | KUHNER |
| 20452101 | REAL |
| 220486 | ERA |
| 220926 | ERA |
| 228000-8540 | DENSO |
| 228000-8542 | DENSO |
| 25-2422 | ELSTOCK |
| 28100-0M051 | TOYOTA |
| 281002102 | TOYOTA |
| 2810021020 | TOYOTA |
| 28100-21020 | DENSO |
| 2810021021 | TOYOTA |
| 2810021022 | TOYOTA |
| 2810021030 | TOYOTA |
| 28100-21030 | TOYOTA |
| 2810021031 | TOYOTA |
| 28100-21031 | TOYOTA |
| 2810021040 | TOYOTA |
| 28100-21050 | TOYOTA |
| 3T356 | JAPKO |
| 3T376 | JAPKO |
| 6044101 | SANDO |
| 8EA737971-001 | HELLA |
| 91-29-5496N | WILSON |
| 9709 | CEVAM |
| CGB-28540 | AINDE |
| CST44101 | CASCO |
| CST44101AS | CASCO |
| CST44101ES | CASCO |
| CST44101GS | CASCO |
| CST44101OS | CASCO |
| CST44101RS | CASCO |
| DRS3866 | DELCO |
| DSN934 | DENSO |
| F032113314 | CARGO |
| F042S00207 | UNIPOINT |
| J5212104 | HERTH+BUSS |
| JS1224 | HC PARTS |
| LRS01479 | LUCAS |
| LRS1479 | LUCAS |
| MAV461090 | SIOM |
| MAV5970 | SIOM |
| MTT356 | JAPANPARTS |
| MTT376 | JAPANPARTS |
| S12DE0226 | SIDAT |
| S12DE0226A2 | SIDAT |
| S131.429 | PSH |
| STN1224 | KRAUF |
| STR6164 | ELECTROLOG |
| STX201013 | STARDAX |
| UD20534S | AS-PL |
Video/Publications
