Associated Numbers
255229D 28100-0T170 28100-0T260 28100-0T290 28100-0T300 28100-37090 28100-37110 28100-37120 438000-0650 91-29-5845 CST40392 CST40392AS CST40392ES CST40392GS CST40392OS CST40392RS DSN1239 S6304S STN3219 STN4219 UD20508SSpecifications
| Kilowatt | 1.3 kW |
| Length (L.1) | 193 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 11 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Corolla 1.8 | ||
| TOYOTA | RAV4 2.0 | 12.2008-06.2013 | |
| TOYOTA | RAV4 2.0 4WD | 12.2008-06.2013 |
Reference Information
28100-0T300 28100-37110 91-29-5845 28100-37120 STRE395 28100-0T170 DSN1239 28100-0T260 28100-37090 STN3219 220830 CST40392RS S6304S STN4219 28100-0T290 CST40392OS CST40392 255229D UD20508S CST40392GS CST40392ES 438000-0650 CST40392ASVideo/Publications
255229D 28100-0T170 28100-0T260 28100-0T290 28100-0T300 28100-37090 28100-37110 28100-37120 438000-0650 91-29-5845 CST40392 CST40392AS CST40392ES CST40392GS CST40392OS CST40392RS DSN1239 S6304S STN3219 STN4219 STRE395 UD20508S 220830Add Your Number
