Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 413.43 including GST
NZ$ 359.50 excluding GST
or four payments of $103.36
with
Learn More
UOM:
each
Product Code:
S6289S
No stock in NZ currently
No stock in NZ currently
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
438000-1790Associated Numbers
190.955.102 20432194BN 28100-0L180 438000-1790 6040491 CST40491AS UD14906S
28100-11190 4380003100 TG4380003100
16-729 16-533
Specifications
| Kilowatt | 1.80 kW |
| Length (L.1) | 227 mm |
| Mount Hole Center - Center (O.1) | 129 mm |
| Mount Hole Diameter (C.1) | M12x1.25 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 17 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.50 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Hilux 2.8 | 01.2015- | |
| TOYOTA | Hilux 3.0 | 01.2015- |
Reference Information
| 190.955.102.050 | PSH |
| 20432194BN | REAL |
| 25-5258 | ELSTOCK |
| 28100-0L180 | TOYOTA |
| 28100-11190 | TOYOTA |
| 28100-11210 | DENSO |
| 31135N | WAI / TRANSPO |
| 438000-1790 | DENSO |
| 438000-3100 | DENSO |
| 438000-5000 | DENSO |
| 6040491.0 | SANDO |
| 88214453 | POWERMAX |
| AM-2602 | AUTO MAGNETO |
| ASM2025 | APEC |
| CST40491AS | CASCO |
| LRS04095 | LUCAS |
| LRS4095 | LUCAS |
| NPANSM2025 | NAPA |
| S131.380 | PSH |
| S1358D | PRESTOLITE |
| S6289S | AS-PL |
| STR6677 | ELECTROLOG |
| STR70589 | WOODAUTO |
| UD102266S | AS-PL |
| UD104370S | AS-PL |
| UD104577S | AS-PL |
| UD14906S | AS-PL |
| WOOSTR70589 | WOODAUTO |
Video/Publications
