Associated Numbers
0R4321 1006929 114268 143-0541 143-0543 18505N 225-3150 228000-1830 228000-1831 228000-1832 246-25242 254258 254258L 45-4267 6040619 641.503.103 8182 88214710 91-26-5423 CST40619 CST40619AS CST40619ES CST40619GS CST40619OS CST40619RS DRS0206 LRS02594 S-8655 STI4268SU STN4268 STN4268SU STR70125Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 298 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 30 mm |
Rotation | CW |
Spigot Diameter (A) | 88.5 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | 924G 6.0 | [3056E] | 01.2000-12.2007 |
CATERPILLAR | 924GZ | [3056T] | 01.2000-12.2007 |
CATERPILLAR | CS-433C | [3054T] | 01.1998-12.2005 |
HYDREMA | 926D 4.4 | [1104D-44TA] | 01.2009- |
TEREX | TL160 4.4 | [1104D-44T] | 01.2006-12.2013 |
Reference Information
641.503.103.510 6040619 CGB-23162 114268 228080-1832 143-0541 641.503.103.050 OR4321 1006929 45-4267 5140095 6040619.1 225-7304 STR6580 STN4268 2873K406 LRS02594 S6282S LRS2594 PRSL170 88214710 STR70125 20432916BN 228000-1830 228000-1831 CST40619GS 228000-1832 0R4321 225-3150 9722809183 8182 20432916OE 641.503.103.260 S24DE0093 S24DE0093A2 91-26-5423 STRL170 S-8655 18505N DRS0206 254258 336543 143-0543 254258L DSN2042 CST40619AS 246-25242 MAV426190Video/Publications
0R4321 1006929 114268 143-0541 143-0543 18505N 228000-1830 228000-1831 228000-1832 246-25242 254258 254258L 45-4267 6040619 641.503.103 8182 88214710 91-26-5423 CST40619 CST40619AS CST40619ES CST40619GS CST40619OS CST40619RS DRS0206 DSN2042 LRS02594 LRS2594 MAV426190 S-8655 S6282S STI4268SU STN4268 STN4268SU STR70125Add Your Number
