Associated Numbers
0001108070 0001108105 0001108135 0001110024 0986019220 111456 11676 128000-3500 128000-7500 128000-8030 1702N 1702R 20762 25-2036 4419340 4467185 4671084 4686179 5227248 5234648 8212588 830.510.093 88212588 91-29-5093 91-29-5093N 943207621010 944280800700 AEY1298 DRZ5163 JS762 LRS01298 R4557284 S-8214 STB0762 STB0762NX UD14890SSpecifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 236 mm |
| Mount Hole Center - Center (O.1) | 71 mm |
| Mount Hole Center - Center (O.2) | 67 mm |
| Mount Hole Center - Center (O.3) | 113 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 8 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | Daytona 3.0 | 01.1990-12.1993 | |
| CHRYSLER | Dynasty 3.0 | 01.1988-01.1990 | |
| CHRYSLER | LeBaron 3.0 i V6 | [EFA] | 01.1988-12.1995 |
| CHRYSLER | New Yorker 3.0 | 01.1988-12.1989 | |
| CHRYSLER | Saratoga 3.0 i | [6G72] | 01.1989-12.1995 |
| CHRYSLER | TC Masterati 3.0 | 01.1990-12.1991 | |
| CHRYSLER | Voyager 3.0 V6 | [6G72] | 01.1990-12.1995 |
| CHRYSLER | Voyager 3.0 V6 | [6G72] | 01.1996-12.2000 |
| DODGE | Caravan 3.0 | 01.1987-12.1995 | |
| DODGE | Grand Caravan 3.0 | 01.1987-12.1995 | |
| DODGE | Mini Ram 3.0 | 01.1987-12.1988 | |
| DODGE | Royal Mini Ram 3.0 | 01.1987-12.1987 | |
| DODGE | Shadow 3.0 | 01.1992-12.1994 | |
| DODGE | Spirit 3.0 | 01.1989-12.1995 | |
| PLYMOUTH | Acclaim 3.0 | 01.1989-12.1995 | |
| PLYMOUTH | Grand Voyager 3.0 | 01.1987-12.1995 | |
| PLYMOUTH | Sundance 3.0 | 01.1992-12.1994 | |
| PLYMOUTH | Voyager 3.0 | 01.1987-12.1995 |
Reference Information
R4557284 5227248 111456 8212588 91-29-5093N 0001108135 AEY1298 1108135 9.44281E+11 CGB-25163 DRZ5163 4419340 4686179 986019220 1108070 0001108070 25-2036 91-29-5093 ANM97383X UD14890S 4671084 4467185 5234648 S-8214 0001108105 20762 128000-3500 830.510.093 LRS1298 1108105 1110024 128000-7500 000986019220 1702R 0001110024 1702N STB0762 JS762 LRS01298 STRF073 STB0762NX 88212588 9.43208E+11 11676 128000-8030Video/Publications
0001108070 0001108105 0001108135 0001110024 0986019220 111456 11676 128000-3500 128000-7500 128000-8030 1702N 1702R 20762 25-2036 4419340 4467185 4671084 4686179 5227248 5234648 8212588 830.510.093 88212588 91-29-5093 91-29-5093N 943207621010 944280800700 AEY1298 CGB-25163 DRZ5163 JS762 LRS01298 LRS1298 R4557284 S-8214 STB0762 STB0762NX STRF073 UD14890SAdd Your Number
