Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 417.25 including GST
NZ$ 362.83 excluding GST
or four payments of $104.31
with
Learn More
each
S6004
S6278S
No stock in NZ currently
No stock in NZ currently
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
228000-3852Associated Numbers
190-20121 19907N 20552 20552V 228000-3850 228000-3851 228000-3852 246-20122 8971128650 8971128651 8971128652 91-29-5630 DENDSN2063 DSN2063 S-80140 16920
Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 222 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | 13 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 19 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 95 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALLMAND | Maxi-Lite | [4LE1] | 01.1994-12.2005 |
| DENYO | DCA-25PI-C | [4LE1] | 01.2001-12.2006 |
| DENYO | DIS-180SB | [4LE1] | 01.2001-12.2006 |
| DENYO | DIS-180SS | [4LE1] | 01.2001-12.2006 |
| GENIE | AL5000 | [4LE1PV02-506] | |
| GENIE | AL5000 | [4LE2-522] | |
| GENIE | AL8000HT | [4LE1PV02-502] | |
| GENIE | T15 | [4LE1PV02-502] | |
| GENIE | T25 | [4LE1PV02-502] | |
| GENIE | T45 | [4JG1TPV] | |
| GENIE INDUSTRIES | AL5000 | [4LE1PV02-506] | |
| GENIE INDUSTRIES | AL5000 | [4LE2-522] | |
| GENIE INDUSTRIES | AL8000HT | [4LE1PV02-502] | |
| GENIE INDUSTRIES | T15 | [4LE1PV02-502] | |
| GENIE INDUSTRIES | T25 | [4LE1PV02-502] | |
| GENIE INDUSTRIES | T45 | [4JG1TPV] | |
| HITACHI | EX27U | [3LD1-PA41] | |
| HITACHI | EX35U | [3LD1-PA33] | |
| HITACHI | EX40U | [4LE1] | 01.1997-12.2004 |
| HITACHI | EX50U | [4LE1] | 01.1999-12.2001 |
| HITACHI | EX50UNA | [4LE1-PA07] | |
| HITACHI | EX50UNA | [4LE1-PA19] | |
| HITACHI | ZAXIS 50U | [CC4LE2-PA02] | |
| HITACHI | ZX50U | [CC4LE2-PA02] | |
| ISUZU | Engine | [4LE1] | 01.1996-12.2006 |
| ISUZU | Engine | [4LE1PV] | 01.1988-12.2003 |
| JOHN DEERE | 27CZTS | [3LD2] | 01.2003-12.2006 |
| JOHN DEERE | 35CZTS | [3LD2] | 01.2003-12.2005 |
| JOHN DEERE | 50CZTS | [4LE2] | 01.2003-12.2005 |
| JOHN DEERE | 50ZTS | [4LE1] | 01.1999-12.2002 |
| MER EQUIPMENT | MG18 | [4LE1] | |
| MER EQUIPMENT | MP55 | [4LE1] | |
| THOMAS BUILT BUSES | T45S | [4LE1] | 01.1991-12.2005 |
| THOMAS IND | T45S | [4LE1] | 01.1991-12.2005 |
Reference Information
| 190-20121 | ROBERT'S |
| 19906N | WAI / TRANSPO |
| 19907N | WAI / TRANSPO |
| 20432901BN | REAL |
| 20552 | KUHNER |
| 20552V | KUHNER |
| 228000-3850 | DENSO |
| 228000-3851 | DENSO |
| 228000-3852 | DENSO |
| 246-20122 | DIXIE |
| 2912559140 | ISUZU |
| 5811000800 | ISUZU |
| 5811001550 | ISUZU |
| 5811001830 | ISUZU |
| 5811001831 | ISUZU |
| 6040109.0 | SANDO |
| 62811000023 | ISEKI |
| 65262017039 | CHEVROLET |
| 65262017059 | CHEVROLET |
| 8970489650 | ISUZU |
| 8970489660 | ISUZU |
| 8970489661 | ISUZU |
| 8970489662 | ISUZU |
| 8970489672 | ISUZU |
| 8970489673 | ISUZU |
| 8970848770 | ISUZU |
| 8971128650 | ISUZU |
| 8971128651 | ISUZU |
| 8971128652 | ISUZU |
| 91-29-5630 | WILSON |
| 9821006070 | ISUZU |
| 9821006170 | ISUZU |
| CST40109AS | CASCO |
| DENDSN2063 | WOODAUTO |
| DSN2063 | DENSO |
| MAV221140 | SIOM |
| MAV5000A | SIOM |
| S6278S | AS-PL |
| S-80140 | DIXIE |
| STX200239 | STARDAX |
| STX200820 | STARDAX |
| UD14891S | AS-PL |
Video/Publications
