Associated Numbers
116092 12249 1608064680 20432914BN 220.536.103 220.536.103.260 25-5011 255320 255320D 31233N-OS 3244 428000-8330 428000-8331 428000-8332 6040419 9671530880 9688477380 AEX1167 AEY3838 CST40419 CST40419AS CST40419ES CST40419GS CST40419OS CST40419RS DENDSN1368 DRS0931 DSN1368 LRS03838 RAS31042 S6235S STN3838 UD13039SSpecifications
Kilowatt | 1 kW |
Length (L.1) | 178 mm |
Mount Hole Center - Center (O.1) | 123.5 mm |
Mount Hole Center - Center (O.2) | 75 mm |
Mount Hole Center - Center (O.3) | 91.5 mm |
Mount Hole Diameter (C.1) | 9.5 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 14.5 mm |
Rotation | CW |
Spigot Diameter (A) | 72 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CITROEN | C1 1.2 VTi | [HMT(EB2D)] | 04.2014- |
CITROEN | C3 1.0 VTi | [ZMZ(EB0)] | 08.2012- |
CITROEN | C3 1.2 VTi | [HMZ(EB2F)] | 06.2012- |
CITROEN | C4 Cactus 1.2 VTi | [HMU(EB2D)] | 09.2014- |
CITROEN | C-Elysee 1.2 VTi | [HMY(EB2M)] | 11.2012- |
CITROEN | C-Elysee 1.2 VTi | 12.2014- | |
CITROEN | DS3 1.2 VTi | [HMZ(EB2F)] | 01.2013-03.2015 |
CITROEN | DS3 1.2 VTi | [HMZ(EB2F)] | 01.2013-07.2015 |
PEUGEOT | 108 1.2 | [HMT(EB2D)] | 05.2014- |
PEUGEOT | 2008 1.2 VTi | [HMZ(EB2F)] | 03.2013- |
PEUGEOT | 208 1.0 | [ZMZ(EB0)] | 03.2012- |
PEUGEOT | 208 1.2 | [HMZ(EB2F)] | 03.2012- |
PEUGEOT | 301 1.2 VTi | 12.2014- |
Reference Information
UD13039S CST40419ES CST40419GS 9671530880 CST40419AS 3244 STN3838 255320 6040419 STR6547 95525944 220970 CST40419OS DENDSN1368 AEY3838 DRS0931 RAS31042 CST40419RS 116092 31233N-OS 1608064680 CST40419 3639503 20432914BN LRS3838 428000-8330 S12DE0833A2 220.536.103 255320D DSN1368 S6235S 9688477380 160806468 428000-8332 428000-8331 AEX1167 220.536.103.260 LRS03838 25-5011 STRE423 12249Video/Publications
116092 12249 1608064680 20432914BN 220.536.103 220.536.103.260 25-5011 255320 255320D 31233N-OS 3244 428000-8330 428000-8331 428000-8332 6040419 9671530880 9688477380 AEX1167 AEY3838 CST40419 CST40419AS CST40419ES CST40419GS CST40419OS CST40419RS DENDSN1368 DRS0931 LRS03838 LRS3838 RAS31042 S6235S STN3838 STRE423 UD13039S 220970Add Your Number
