Associated Numbers
0986019141 190.541.092 20918 228000-0940 25-2290 66925179 88213283 8EA737119-001 944280522770 9512 DRS3643 J5212077 LRT00129 STN0918 STR50037 UD13773SSpecifications
Kilowatt | 0.8 kW |
Length (L.1) | 201 mm |
Mount Hole Center - Center (O.1) | 133 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 8.5 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Carina E 1.6 | [4A-FE] | 01.1992-12.1997 |
TOYOTA | Carina E 1.8 | [7A-FE] | 01.1994-12.1998 |
TOYOTA | Celica 1.8 i 16V | [7A-FE] | 01.1994-12.1999 |
TOYOTA | Corolla 1.6 | [4A-FE] | 01.1995-12.1999 |
TOYOTA | Corona 1.6 | [4A-FE] | 01.1992-12.1997 |
Reference Information
LRT00129 111455 9.44281E+11 MTT231 28100-16041 986019141 28100-16160 28100-16040 2.81009E+12 JS918 2810016160 STR50037 J5212077 DRS3643 336050 3T231 25-2290 8EA737119-001 003-T231 UD13773S 88213283 228000-0940 28100-87213 STN0918 MAV461110 28100-16010 28100-16230 9512 000986019141 STR6313 28100-16070 28100-16071 20918 2810016230 66925179 190.541.092 CGB-23643Video/Publications
003-T231 0986019141 111455 190.541.092 20918 228000-0940 25-2290 3T231 66925179 88213283 8EA737119-001 944280522770 9512 CGB-23643 DRS3643 J5212077 JS918 LRT00129 MAV461110 MTT231 STN0918 STR50037 UD13773SAdd Your Number
