Associated Numbers
115595 17121-63013 17121-63014 19648N 228000-4740 228000-4741 25-4365 255492 88214051 DRS0979 LRS02693 UD13638SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 221 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KUBOTA | F2803 2.0 | 01.1991-12.1999 |
Reference Information
S12DE0728A2 19648N 88214051 S6217S 255492 DRS0979 228000-4740 228000-4741 STR6814 6040526 CST40526AS 25-4365 115595 LRS02693 UD13638S 20432625BN LRS2693 5040650 17121-63014 17121-63013 MAV425260AVideo/Publications
115595 17121-63013 17121-63014 19648N 228000-4740 228000-4741 25-4365 255492 88214051 DRS0979 LRS02693 LRS2693 S6217S UD13638SAdd Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
