Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 403.65 including GST
NZ$ 351.00 excluding GST
or four payments of $100.91
with
Learn More
each
S6193
1
Associated Numbers
063280093010 20432053OE 255344D 428000-8700 428000-8701 480.516.132 6040350 63280093 8EA012140-551 9A160410900 9A1604109X CST40350 CST40350AS CST40350ES CST40350GS CST40350OS CST40350RS DSN972 UD12917SSpecifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 230 mm |
| Mount Hole Center - Center (O.1) | 110 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| OEM Product | No |
| Pinion at Rest (B) | 54 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| PORSCHE | 911 3.4 Carrera | [MA1.04] | 12.2011- |
| PORSCHE | 911 3.4 Carrera | [MAB.04] | 12.2011- |
| PORSCHE | 911 3.8 Carrera S | [MA1.03] | 12.2011- |
| PORSCHE | 911 3.8 Carrera S | [MAB.03] | 12.2011- |
| PORSCHE | Boxster 2.7 | [MA1.22] | 04.2012- |
| PORSCHE | Boxster S 3.4 | [MA1.23] | 04.2012- |
Reference Information
| 063280093010 | MAGNETI MARELLI |
| 10952N | WAI / TRANSPO |
| 20432053OE | REAL |
| 255344D | KUHNER |
| 428000-8700 | DENSO |
| 428000-8701 | DENSO |
| 480.516.132 | PSH |
| 6040350 | SANDO |
| 63280093 | MAGNETI MARELLI |
| 8EA012140-551 | HELLA |
| 9A160410900 | PORSCHE |
| 9A1604109X | PORSCHE |
| CST40350 | CASCO |
| CST40350AS | CASCO |
| CST40350ES | CASCO |
| CST40350GS | CASCO |
| CST40350OS | CASCO |
| CST40350RS | CASCO |
| DSN972 | DENSO |
| S132.894 | PSH |
| STR6448 | ELECTROLOG |
| UD104403S | AS-PL |
| UD12917S | AS-PL |
