Associated Numbers
11020350 EuroTec 11040777 11040831 11090346 120576092 PSH 12318 EAI 17886 Lester 254151 Elstock 31200RAD003 Honda 31200RBA003 322060092 DRI 3937 CEVAM 4280000011 Denso 4280000012 4280000013 4280000280 show 4280001350 4280001350SEL +line 4280001351 4280001352 4280001353 428000136 4280001360 4280001361 4280001362 4280001363 4280801350 910622 EDR A20350 ATL AHS208 ATK AHS213 DKSE7 DRS0622 Remy DSDH9 DSDHG DSKE7 DSN1406 LRS01701 Lucas LRS1718 LRS2479 SM612610 Mitsuba DXS4035 70-8113 SNJ326 mxs364 70-2846 S17816 17816 31200RFE004 31200RTB014 sm71009
31200PNA003 2280009861 2280009860 2280009862 31200pnc013
Specifications
Will Replace the Mitsuba Version.
Kilowatt | 1.2 kW |
Length (L.1) | 216 mm |
Mount Hole Center - Center (O.1) | 115 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 32.5 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ACURA | RSX 2.0 | 01.2002-12.2006 | |
HONDA | Accord 2.4i | [K24A] | 01.2003-12.2008 |
HONDA | Civic 2.0 Type-R | [K20A2] | 01.2001-12.2005 |
Reference Information
17886N CST40313OS 17340 91-29-5675 120.576.092 S6192 336478 31200-RAD-003 31200PRBA01 RNL428000-0010 ANM12673X 31200PRBA01RM 428000-1350 DRS0453 UD00880S DSDH9 9634 LRS01718 S-80020 EAA-121742 CST40313 CST40313RS 428000-3280 20432313RC 254479 31200PRBA11 DSDHG AEY1718 6040313 LRS1718 428000-0011 31200PRBA11RM 428000-0010 428000-0013 428000-0012 CST40313AS 12105 17886R 25-3274 CST40313GS DSDHL CST40313ESVideo/Publications
120.576.092 12105 17340 17886N 17886R 20432313RC 25-3274 254479 31200-RAD-003 31200PRBA01 31200PRBA01RM 31200PRBA11 31200PRBA11RM 428000-0010 428000-0011 428000-0012 428000-0013 428000-1350 428000-3280 6040313 91-29-5675 9634 AEY1718 CST40313 CST40313AS CST40313ES CST40313GS CST40313OS CST40313RS DRS0453 DSDH9 DSDHG DSDHL EAA-121742 LRS01718 LRS1718 RNL428000-0010 S-80020 UD00880SAdd Your Number
