Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 728.97 including GST
NZ$ 633.89 excluding GST
or four payments of $182.24
with
Learn More
each
S6186
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
428000-4080Associated Numbers
18568N 190-50108 201228 201228D 228000-6540 228000-6541 228000-9140 246-50108 428000-4080 91-29-5831 RE504244 RE506105 RE528619 RE529661 RE70473 RE70959 S-80434 SE501853 SE501866 SE501867 TY24440 UD12386SSpecifications
| Kilowatt | 4.8 kW |
| Length (L.1) | 316 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 12 mm |
| Mount Hole Diameter (C.2) | 12 mm |
| Mount Hole Diameter (C.3) | 12 mm |
| No./Mount holes | 4 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | 344J | [4045HT] | |
| JOHN DEERE | 350D LC | [6090HT] | |
| JOHN DEERE | 3520 | [6090HT] | |
| JOHN DEERE | 4930 | [6-551] | |
| JOHN DEERE | 7180 | [6090HZ] | |
| JOHN DEERE | 7250 | [6090HZ] | |
| JOHN DEERE | 8130 | [6-548] | 01.2005-12.2009 |
| JOHN DEERE | 8230 | [6-548] | 01.2005-12.2009 |
| JOHN DEERE | 8230T | [6-548] | 01.2005-12.2009 |
| JOHN DEERE | 8330 | [6-548] | 01.2005-12.2009 |
| JOHN DEERE | 8330T 8.9 | [6-548] | 01.2005-12.2009 |
| JOHN DEERE | 8430 | [6-548] | 01.2005-12.2009 |
| JOHN DEERE | 8430T 8.9 | [6-548] | 01.2005-12.2009 |
| JOHN DEERE | 8530 8.9 | [6-548] | 01.2005-12.2009 |
| JOHN DEERE | 9230 8.9 | [6-548] | 01.2007-12.2011 |
| JOHN DEERE | 9660 STS 8.1 | [6081] | |
| JOHN DEERE | 9670 STS 8.9 | 01.2007-12.2011 | |
| JOHN DEERE | 9760 STS 8.1 | [6081] | |
| JOHN DEERE | 9770 STS 8.9 | 01.2007-12.2009 | |
| JOHN DEERE | CH570 | [6090HT] | |
| JOHN DEERE | CH670 | [6090HT] | |
| JOHN DEERE | T560 | [6090HZ007] | |
| JOHN DEERE | T660 | [6090HZ] | |
| JOHN DEERE | T670 | [6090HZ] |
Reference Information
| 18568N | WAI / TRANSPO |
| 190-50108 | ROBERT'S |
| 201228 | KUHNER |
| 201228D | KUHNER |
| 20432333BN | REAL |
| 20432333OE | REAL |
| 228000-6540 | DENSO |
| 228000-6541 | DENSO |
| 228000-9140 | DENSO |
| 246-50108 | DIXIE |
| 428000-4080 | DENSO |
| 6040333.0 | SANDO |
| 6040333.1 | SANDO |
| CST40333AS | CASCO |
| CST40333GS | CASCO |
| MAV422020 | SIOM |
| MAV423330A | SIOM |
| RA69704 | JOHN DEERE |
| RE504244 | JOHN DEERE |
| RE506105 | JOHN DEERE |
| RE528619 | JOHN DEERE |
| RE529661 | JOHN DEERE |
| RE65191 | JOHN DEERE |
| RE70473 | JOHN DEERE |
| RE70959 | JOHN DEERE |
| S6186 | AS-PL |
| S-80434 | DIXIE |
| SE501853 | JOHN DEERE |
| SE501866 | JOHN DEERE |
| SE501867 | JOHN DEERE |
| STR6053 | ELECTROLOG |
| TY24440 | JOHN DEERE |
| UD12386S | AS-PL |
Video/Publications
