Associated Numbers
25-4177 255194 28100-B1020 28100-B2120 428000-2560 428000-5080 AEY2505 DRS0655 LRS02505 S6176 UD12039SSpecifications
Kilowatt | 1 kW |
Length (L.1) | 222 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 36 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DAIHATSU | Cuore 1.0 | [1KR-FE] | 01.2007- |
DAIHATSU | Sirion 1.0 | [1KR-FE] | 01.2005- |
SUBARU | Justy 1.0 | [1KR-FE] | 01.2007- |
TOYOTA | Passo 1.0 | [1KR-FE] | 01.2005-12.2010 |
TOYOTA | Passo 1.0 4x4 | [1KR-FE] | 01.2005-12.2010 |
Reference Information
28100-B2120 28100-B2110 28100B2110 LRS2505 28100-B1020 S6176 STR6314 428000-5080 255194 AEY2505 UD12039S CST40012 20432210 428000-2560 DRS0655 6040012 25-4177 LRS02505Video/Publications
25-4177 255194 28100-B1020 28100-B2120 428000-2560 428000-5080 AEY2505 DRS0655 LRS02505 LRS2505 S6176 UD12039SAdd Your Number
