Associated Numbers
16096 190.909.092 19045N 19045R 254985 28100-0S010 28100-0S011 28100-38040 28100-38041 428000-3960 428000-4640 428000-4641 91-29-5749 S-80401 S-80409 S6165 UD12049SSpecifications
| Kilowatt | 2 kW |
| Length (L.1) | 230 mm |
| Mount Hole Center - Center (O.1) | 103 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 22 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LEXUS | LX570 5.7 | 01.2008-12.2011 | |
| TOYOTA | Land Cruiser 5.7 | 01.2008-12.2011 | |
| TOYOTA | Sequoia 5.7 | 01.2008-12.2011 | |
| TOYOTA | Tundra Pickup 5.7 | 01.2007-12.2011 |
Reference Information
5040618 16096 28100-0S011 28100-0S010 S6165 MAV424940A 28100-38041 28100-38040 UD12049S CST40494AS 91-29-5749 254985 S-80409 19045N 428000-3960 428000-4641 6040494 428000-4640 20432494BN 190.909.092 S-80401 S12DE0592A2 19045RVideo/Publications
16096 190.909.092 19045N 19045R 254985 28100-0S010 28100-0S011 28100-38040 28100-38041 428000-3960 428000-4640 428000-4641 91-29-5749 S-80401 S-80409 S6165 UD12049SAdd Your Number
