Associated Numbers
03112-70810 UD02123Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 298 mm |
Mount Hole Center - Center (O.1) | 111 mm |
Mount Hole Center - Center (O.2) | 111 mm |
Mount Hole Center - Center (O.3) | 135 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
Mount Hole Diameter (C.3) | 13 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DAEWOO | Various Models |
Reference Information
231.502.113.360 231.502.113.170 65.26201-7043 03112-70810 S6131 UD02123 254953VVideo/Publications
03112-70810 231.502.113.170 231.502.113.360 254953V 65.26201-7043 UD02123Add Your Number
