Associated Numbers
28100-0D030 S6100 UD00740SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 189 mm |
Mount Hole Center - Center (O.1) | 117 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 13 qty |
No./Teeth (Replaces) | 13 qty |
Pinion at Rest (B) | 4.5 mm |
Rotation | CW |
Spigot Diameter (A) | 50 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Durango 4.7 | 01.2004-12.2005 | |
DODGE | Durango 5.7 | 01.2004-12.2005 |
Reference Information
428000-2050 S6100 91-29-5641 S-80389 STN4051 56029750AA UD00740S 17884NVideo/Publications
17884N 428000-2050 56029750AA 91-29-5641 S-80389 S6100 STN4051 UD00740SAdd Your Number
