Associated Numbers
063280075010 114661 12209 220677 25-3447 254409 254409D 28100-0Q040 28100-0Q041 28100-0Q050 28100-40090 28100-40091 28100-40140 428000-3361 428000-4560 428000-4561 6040320 9754 AEY2276 CS1531 CST40320 CST40320AS CST40320ES CST40320GS CST40320OS CST40320RS DRS0473 DSN948 J5212134 LRS02276 UD809837(DENSO)SSpecifications
Kilowatt | 1.3 kW |
Length (L.1) | 190 mm |
Mount Hole Center - Center (O.1) | 129 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Yaris 1.0 | [1KR-FE | 12.2010- |
TOYOTA | Yaris 1.0 | [1KR-FE] | 06.2018- |
TOYOTA | Yaris 1.0 | [1KR-FE] | 12.2010- |
TOYOTA | Yaris 1.0 GPL | [1KR-FE] | 01.2006-12.2011 |
TOYOTA | Yaris 1.0 VVT-i | [1KR-FE] | 08.2005-12.2011 |
Reference Information
190.903.092.260 6040320.1 STR6303 PRSS888 220677 88214081 003-130002 CS1531 25-3447 LRS02276 254409 28100-40090 DS1583 CST40320AS 28100-40091 190.903.092.050 CST40320GS CGB-24560 254409D 2S0361 9754 MS428000-4560 CGB-53447 428000-3361 428000-3482 STRS888 33277N 428000-3480 12209 428000-3360 428000-3481 114661 RNL428000-4560 63280075010 S12DE0229A2 DSN948 MT130002 20432023OE 28100-0Q040 28100-0Q041 UD809837(DENSO)S SS695 8EA011611-601 428000-4561 428000-4560 S12DE0229 28100-00050 6040320 J5212134 DRS0473 LRS2276 STM1375 20432023BN 28100-0Q050 AEY2276 428000-8230 28100-00041 MSN8075 28100-40140Video/Publications
063280075010 114661 12209 220677 25-3447 254409 254409D 28100-00050 28100-0Q040 28100-0Q041 28100-0Q050 28100-40090 28100-40091 28100-40140 428000-3361 428000-4560 428000-4561 6040320 9754 AEY2276 CS1531 CST40320 CST40320AS CST40320ES CST40320GS CST40320OS CST40320RS DRS0473 DSN948 J5212134 LRS02276 LRS2276 MS428000-4560 UD809837(DENSO)SAdd Your Number
