Associated Numbers
128000-4420 128000-5780 128000-5781 128000-8350 128000-8360 128000-8500 17256N 20432141BN 20560 228000-0311 228000-1710 25-1166 28100-01030 28100-16020 28100-16110 28100-16130 28100-16140 28100-16210 6040141 66925149 AES7123 CST40141AS DRS3058 DS4168 LRS00723 SS697 STR70239 UD00743SSpecifications
Kilowatt | 1 kW |
Length (L.1) | 189 mm |
Mount Hole Center - Center (O.1) | 132 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 9.5 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
GEO | Prizm 1.6 LSI | 01.1993-01.1995 | |
GEO | Prizm 1.8 LSI | 01.1993-01.1995 | |
TOYOTA | Carina 1.6 | [4A-F] | 12.1987-08.1990 |
TOYOTA | Carina 1.6 | [4A-F] | 12.1987-11.1989 |
TOYOTA | Carina 1.6 | [4A-F] | 12.1987-12.1989 |
TOYOTA | Carina 1.6 | [4A-FE] | 12.1987-03.1992 |
TOYOTA | Celica 1.6 | [4A-FE] | 10.1989-11.1993 |
TOYOTA | Celica 1.6 ST | [4A-FE] | 01.1990-01.1993 |
TOYOTA | Corolla 1.5 Levin S | 06.1991-08.1997 | |
TOYOTA | Corolla 1.6 | [4A-F] | 02.1988-05.1992 |
TOYOTA | Corolla 1.6 | [4A-F] | 08.1987-04.1992 |
TOYOTA | Corolla 1.6 | [4A-F] | 08.1987-12.1989 |
TOYOTA | Corolla 1.6 | [4A-FE] | 01.1990-01.1992 |
TOYOTA | Corolla 1.6 | [4A-FE] | 01.1993-01.1994 |
TOYOTA | Corolla 1.6 | [4A-FE] | 08.1988-06.1992 |
TOYOTA | Corolla 1.6 | [4A-FE] | 08.1989-04.1992 |
TOYOTA | Corolla 1.6 | [4A-FE] | 11.1989-06.1993 |
TOYOTA | Corolla 1.6 | 01.1989-01.1989 | |
TOYOTA | Corolla 1.6 DLX | [4A-F] | 01.1988-01.1989 |
TOYOTA | Corolla 1.6 DLX | [4A-FE] | 01.1990-01.1992 |
TOYOTA | Corolla 1.6 GLi | [4A-FE] | 07.1992-04.1997 |
TOYOTA | Corolla 1.6 i | [4A-FE] | 08.1989-04.1992 |
TOYOTA | Corolla 1.6 i 4WD | [4A-FE] | 10.1987-08.1990 |
TOYOTA | Corolla 1.6 LE | [4A-F] | 01.1988-01.1989 |
TOYOTA | Corolla 1.6 LE | [4A-FE] | 01.1990-01.1992 |
TOYOTA | Corolla 1.6 LSX | 01.1992-01.1992 | |
TOYOTA | Corolla 1.6 Si | [4A-FE] | 07.1992-04.1997 |
TOYOTA | Corolla 1.6 SR5 | [4A-F] | 01.1988-01.1989 |
TOYOTA | Corolla 1.6 SR5 | [4A-FE] | 01.1990-01.1991 |
TOYOTA | Corolla 1.6 SR5 | 01.1992-01.1992 | |
TOYOTA | Corolla 1.6 XLi | [4A-FE] | 11.1989-06.1992 |
TOYOTA | Corolla 1.8 | 01.1993-01.1993 | |
TOYOTA | Corolla 1.8 All Trac | 01.1993-01.1993 | |
TOYOTA | Corolla 1.8 DX | [7A-FE] | 01.1993-01.1994 |
TOYOTA | Corolla 1.8 LE | [7A-FE] | 01.1993-01.1994 |
Reference Information
228000-0311 CST40141AS 128000-8500 128000-4420 MTT218 28100-16140 28100-16020 2810016020R 6040141 AES7123 2810016240 CGB-23058 20432141BN MAV3040 28100-16110 28100-16150 28100-16190 2810016050 2810016170 STR70239 28100-01030 128000-5781 128000-5780 17256N DS4168 LRS00723 2280000900 R89FB11000CA SS697 3T218 5010373 LRS723 ANM15278X 25-1166 003-T218 66925149 128000-8360 228000-1710 28100-16210 20560 2810002040 2810016100 28100-16130 2810016220 28100-16050 110713 STR6176 2810016110R DRS3058 128000-8350 UD00743S JS560Video/Publications
003-T218 110713 128000-4420 128000-5780 128000-5781 128000-8350 128000-8360 128000-8500 17256N 20432141BN 20560 228000-0311 228000-1710 25-1166 28100-01030 28100-16020 28100-16110 28100-16130 28100-16140 28100-16210 3T218 6040141 66925149 AES7123 CGB-23058 CST40141AS DRS3058 DS4168 JS560 LRS00723 LRS723 MAV3040 MTT218 SS697 STR70239 UD00743SAdd Your Number
