Associated Numbers
028000-5490 028000-5492 028000-6560 028000-6561 113428 128000-7750 128000-7751 128000-7752 128000-7753 17302N 2-1753-ND 20432171BN 254270 5811001081 5811001690 5811001691 5811001692 6040171 65262017050 7X0994 CST40171ASSpecifications
Kilowatt | 2.5 kW |
Length (L.1) | 298 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Center - Center (O.2) | 134 mm |
Mount Hole Center - Center (O.3) | 110 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 38 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | NPR 3.9 | [4BD1] | 10.1984-12.1996 |
Reference Information
5040608 31115020 0-23000-1980 5811001690 128000-7753 20432171BN 128000-7751 128000-7752 31115021 254270 5810001693 128000-7750 CST40171AS STR6062 113428 5811001081 17302N 2-1753-ND S6088 MAV421710 5810001691 5810001690 7X0994 S12DE0534A2 028000-5490 6040171 5811001692 028000-5492 5811001691 028000-6561 CGB-23028 028000-6560 65262017050Video/Publications
028000-5490 028000-5492 028000-6560 028000-6561 113428 128000-7750 128000-7751 128000-7752 128000-7753 17302N 2-1753-ND 20432171BN 254270 5811001081 5811001690 5811001691 5811001692 6040171 65262017050 7X0994 CGB-23028 CST40171AS MAV421710Add Your Number
