Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 417.14 including GST
NZ$ 362.73 excluding GST
or four payments of $104.29
with
Learn More
each
S6088
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
028000-5490 028000-5492 028000-6560 028000-6561 113428 128000-7750 128000-7751 128000-7752 128000-7753 17302N 2-1753-ND 20432171BN 254270 5811001081 5811001690 5811001691 5811001692 6040171 65262017050 7X0994 CST40171ASSpecifications
| Kilowatt | 2.5 kW |
| Length (L.1) | 298 mm |
| Mount Hole Center - Center (O.1) | 110 mm |
| Mount Hole Center - Center (O.2) | 134 mm |
| Mount Hole Center - Center (O.3) | 110 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| Mount Hole Diameter (C.3) | 13.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 38 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | NPR 3.9 | [4BD1] | 10.1984-12.1996 |
Reference Information
| 0-23000-1980 | NIKKO |
| 028000-5490 | DENSO |
| 028000-5492 | DENSO |
| 028000-6560 | DENSO |
| 028000-6561 | DENSO |
| 031115020 | HYUNDAI / KIA |
| 031115021 | HYUNDAI / KIA |
| 113428 | CARGO |
| 128000-7750 | DENSO |
| 128000-7751 | DENSO |
| 128000-7752 | DENSO |
| 128000-7753 | DENSO |
| 17302N | WAI / TRANSPO |
| 20432171BN | REAL |
| 2-1753-ND | WAI / TRANSPO |
| 254270 | KUHNER |
| 5040608 | MEAT & DORIA |
| 5810001690 | ISUZU |
| 5810001691 | ISUZU |
| 5810001693 | ISUZU |
| 5811001081 | ISUZU |
| 5811001690 | ISUZU |
| 5811001691 | ISUZU |
| 5811001692 | ISUZU |
| 6040171 | SANDO |
| 65262017050 | DAEWOO |
| 7X0994 | CATERPILLAR |
| CGB-23028 | AINDE |
| CST40171AS | CASCO |
| F032113428 | CARGO |
| MAV421710 | SIOM |
| S12DE0534A2 | SIDAT |
| S6088 | AS-PL |
| STR6062 | ELECTROLOG |
