Associated Numbers
128000-8064 1811003240
4280000880 4280000881
8-97602167-1
16-113
Specifications
Kilowatt | 3.2 kW |
Length (L.1) | 298 mm |
Mount Hole Center - Center (O.1) | 150 mm |
Mount Hole Diameter (C.1) | 15 mm |
Mount Hole Diameter (C.2) | 15 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 44 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | FR 32 | ||
ISUZU | FR 33 | ||
ISUZU | FR 500 | [6H1] | |
ISUZU | FR 500 | [6HE1] | |
ISUZU | FR 500 | [6HH1] | |
ISUZU | FSR 700 | ||
ISUZU | FTR | ||
ISUZU | FTR 800 |
