Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 343.22 including GST
NZ$ 298.45 excluding GST
or four payments of $85.81
with
Learn More
UOM:
each
Alternative Item:
S6083(DENSO),S6213S,S6348S
Product Code:
S6083
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
28100-64310Associated Numbers
0001218166 111874 11879 201088 201135 201138 20452501BN 20452501OE 20510182 22.1088 228000-3640 228000-3641 228000-3642 228000-4980 228000-4981 228000-4982 228000-9220 228000-9221 28100-08010 28100-64310 28100-64350 28100-64430 31184N 31185RW 428000-7850 6044105 8052286 8212681 9762 CST44105AS CST44105GS DRS7500 DSN928 EAA-121300 GS003640-A JS1088 RAS38611 S1049B S6083 STR70055 31185RSpecifications
| Kilowatt | 2.20 kW |
| Length (L.1) | 235 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 9. 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 3.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Avensis 2.0 D-4D Verso | [1CD-FTV] | 08.2001- |
| TOYOTA | AVENSIS Estate (_T22_) 2.0 D-4D (CDT220_, CDT220R) | 1CD-FTV | 10.1999-02.2003 |
| TOYOTA | AVENSIS Estate (_T22_) 2.0 D (CT220_) | 2C-T | 10.1997-05.1998 |
| TOYOTA | AVENSIS Estate (_T22_) 2.0 TD (CT220_, CT220R) | 2C-TE | 09.1997-02.2003 |
| TOYOTA | AVENSIS Liftback (_T22_) 2.0 D-4D (CDT220_, CDT220R) | 1CD-FTV | 10.1999-02.2003 |
| TOYOTA | AVENSIS Liftback (_T22_) 2.0 D (CT220_) | 2C-T | 10.1997-05.1998 |
| TOYOTA | AVENSIS Liftback (_T22_) 2.0 TD (CT220_, CT220R) | 2C-TE | 09.1997-02.2003 |
| TOYOTA | AVENSIS (_T22_) 2.0 D-4D (CDT220_, CDT220R) | 1CD-FTV | 10.1999-02.2003 |
| TOYOTA | AVENSIS (_T22_) 2.0 D (CT220_) | 2C-T | 10.1997-05.1998 |
| TOYOTA | AVENSIS (_T22_) 2.0 TD (CT220_, CT220R) | 2C-TE | 09.1997-02.2003 |
| TOYOTA | AVENSIS VERSO (_M2_) 2.0 D (CLM20_, CLM20R) | 1CD-FTV | 08.2001-08.2005 |
| TOYOTA | Carina E 2.0 D | [2C] | 01.1993-01.1996 |
| TOYOTA | Carina E 2.0 D | [2C] | 04.1992-01.1996 |
| TOYOTA | Carina E 2.0 D | [2C] | 08.1992-01.1996 |
| TOYOTA | Carina E 2.0 TD | [2C-T] | 01.1996-09.1997 |
| TOYOTA | CARINA E VI Saloon (_T19_) 2.0 D (CT190) | 2C | 08.1992-01.1996 |
| TOYOTA | CARINA E VI Saloon (_T19_) 2.0 TD (CT190_, CT190R) | 2C-T | 01.1996-09.1997 |
| TOYOTA | CARINA E VI Sportswagon (_T19_) 2.0 D (CT190_, CT190R) | 2C | 01.1993-09.1997 |
| TOYOTA | CARINA E VI Sportswagon (_T19_) 2.0 TD (CT190_, CT190R) | 2C-T | 01.1996-09.1997 |
| TOYOTA | CARINA E VI (_T19_) 2.0 D (CT190) | 2C | 04.1992-01.1996 |
| TOYOTA | CARINA E VI (_T19_) 2.0 TD (CT190) | 2C-T | 01.1996-09.1997 |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 01.2002- |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 05.2003- |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 09.2000-01.2002 |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 09.2000-10.2001 |
| TOYOTA | Corolla 2.0 D-4D | [1CD-FTV] | 09.2000-11.2001 |
| TOYOTA | Corolla 2.0 D-4D Verso | [1CD-FTV] | 01.2002-05.2004 |
| TOYOTA | COROLLA Compact (_E11_) 2.0 D-4D (CDE110_, CDE110R) | 1CD-FTV | 09.2000-01.2002 |
| TOYOTA | COROLLA (_E11_) 2.0 D-4D (CDE110_, CDE110R) | 1CD-FTV | 09.2000-11.2001 |
| TOYOTA | COROLLA (_E12_) 2.0 D-4D (CDE120_, CDE120R) | 1CD-FTV | 01.2002-12.2006 |
| TOYOTA | COROLLA (_E12_) 2.0 D-4D (CDE120R, CDE120L_) | 1CD-FTV | 01.2002-12.2006 |
| TOYOTA | COROLLA (_E12_) 2.0 D-4D (CDE120R, CDE120L_) | 1CD-FTV | 05.2003-02.2007 |
| TOYOTA | COROLLA Estate (_E11_) 2.0 D-4D (CDE110_, CDE110R) | 1CD-FTV | 09.2000-10.2001 |
| TOYOTA | COROLLA Estate (_E12_) 2.0 D-4D (CDE120_, CDE120R) | 1CD-FTV | 01.2002-02.2007 |
| TOYOTA | COROLLA Estate Van (_E11_) 2.0 D4d (CDE110) | 1CD-FTV | 09.2000-10.2001 |
| TOYOTA | COROLLA Liftback (_E11_) 2.0 D-4D (CDE110_, CDE110R) | 1CD-FTV | 09.2000-01.2002 |
| TOYOTA | COROLLA Verso (_E12_) 2.0 D-4D (CDE120_, CDE120R) | 1CD-FTV | 01.2002-05.2004 |
| TOYOTA | COROLLA Verso (ZER_, ZZE12_, R1_) 2.0 D-4D (CUR10_, CUR10R) | 1CD-FTV | 04.2004-03.2009 |
| TOYOTA | Picnic 2.2 D | [3C-TE] | 08.1997-12.2001 |
| TOYOTA | PICNIC (_XM1_) 2.2 D (CMX10_, CXM10G) | 3C-TE | 08.1997-12.2001 |
| TOYOTA | Previa 2.0 D-4D | [1CD-FTV] | 03.2001-01.2006 |
| TOYOTA | PREVIA II (_R3_) 2.0 D-4D (CLR30_, CLR30R) | 1CD-FTV | 03.2001-01.2006 |
| TOYOTA | RAV4 2.0 D-4D 4WD | [1CD-FTV] | 09.2001-11.2005 |
| TOYOTA | RAV 4 II (_A2_) 2.0 D 4WD (CLA20_, CLA21_, CLA20R, CLA21R) | 1CD-FTV | 05.2001-11.2005 |
Reference Information
| 003-T359 | ASHIKA |
| 063280052010 | MAGNETI MARELLI |
| 10044105AV | ITAB AUTOMOTIVE |
| 10044105OV | ITAB AUTOMOTIVE |
| 10440683 | ALANKO |
| 105365 | FARCOM |
| 111874 | CARGO |
| 11879 | EAI |
| 1638127180 | EUROREPAR |
| 190.552.102.050 | WAI |
| 190.552.102.056 | WAI |
| 190.552.102.260 | WAI |
| 193063 | FEBI BILSTEIN |
| 201088 | KUHNER |
| 201088D | KUHNER |
| 201135 | KUHNER |
| 20452501BN | REAL |
| 20452501OE | REAL |
| 20510182 | PRESTOLITE |
| 220094 | ERA |
| 220703 | ERA |
| 22.1088 | LAUBER |
| 228000-3640 | DENSO |
| 228000-3641 | DENSO |
| 228000-3642 | DENSO |
| 228000-9220 | DENSO |
| 228000-9221 | DENSO |
| 25-3105 | ELSTOCK |
| 28100-64140 | TOYOTA |
| 2810064140 | TOYOTA |
| 28100-64310 | TOYOTA |
| 28100-64430 | TOYOTA |
| 2S0414 | RIDEX |
| 2S0414R | RIDEX |
| 3113784 | HENKEL PARTS |
| 3113785 | HENKEL PARTS |
| 3113786 | HENKEL PARTS |
| 31185R | WAI |
| 31185RW | WAI |
| 335043102 | DRI |
| 335985 | LOGISTIK |
| 3T359 | JAPKO |
| 428000-7850 | DENSO |
| 458580 | VALEO |
| 46TO003 | RED-LINE |
| 5040063 | MEAT & DORIA |
| 546512 | HART |
| 6044105.0 | SANDO |
| 6044105.1 | SANDO |
| 63280052 | MAGNETI MARELLI |
| 803-17083 | IAP QUALITY PARTS |
| 8052286 | FRIESEN |
| 8212681 | POWERMAX |
| 879ST11 | STARTCAR |
| 88212681 | POWERMAX |
| 8EA012526-021 | HELLA |
| 943210881010 | MAGNETI MARELLI |
| 944280522860 | MAGNETI MARELLI |
| 9762 | CEVAM |
| A20580 | ATL AUTOTECHNIK |
| AC-JBS1088 | ACAUTO |
| AES1227 | AUTOELECTRO |
| ANM19720X | ANDEL |
| AZMT-53-010-1116 | A.Z. MEISTERTEILE |
| BST2102 | BORG & BECK |
| CST44105AS | CASCO |
| CST44105GS | CASCO |
| DRS7500 | DELCO |
| DSN928 | DENSO |
| EST-9058 | KAVO PARTS |
| F032111874 | CARGO |
| GS003640-A | GPARTS |
| H5040063 | HOFFER |
| IR8499 | PROTECH |
| J5212086 | HERTH+BUSS |
| JS1088 | HC PARTS |
| LRS01591 | LUCAS |
| LRS1591 | LUCAS |
| MAV5960 | SIOM |
| MRS52286 | MAGNETI MARELLI |
| MSN8052 | MAGNETI MARELLI |
| MSRC1088 | MAGNETI MARELLI |
| MTT359 | JAPANPARTS |
| PRSS025 | 3EFFE |
| RAS38611 | DELCO |
| RE85002N | THE NEW LINE |
| RNL1088JS | RNL |
| S1049B | PRESTOLITE |
| S12DE0167 | SIDAT |
| S12DE0167A2 | SIDAT |
| S131.407 | WAI |
| S145.615 | WAI |
| S512244 | BTS TURBO |
| S6083 | AS-PL |
| SG0229 | GHIBAUDI |
| SKSTR-0330413 | STARK |
| ST01188 | TMI |
| STA0546R | BOVEZ |
| STO105 | AUTOTEAM |
| STO105A | AUTOTEAM |
| STR6736 | ELECTROLOG |
| STR70055 | WOODAUTO |
| STRS025 | 3EFFE |
| STX200089 | STARDAX |
| STX200089R | STARDAX |
| TO9043 | SNRA |
| TT15639 | TESLA |
| WG2013264 | WILMINK GROUP |
| WG2174915 | WILMINK GROUP |
| WOOSTR70055 | WOODAUTO |
Video/Publications
