Associated Numbers
12019 17890N 201320 20432261BN 20432261OE 22.1320 22.1320M 228000-7710 25-3028 3665 6040162 8080206 8213230 AEY1542 CST40162AS CST40162GS DSN603 JS1320 LRS01542 NAD100952 NAD100952L SS663Specifications
Kilowatt | 2 kW |
Length (L.1) | 240 mm |
Mount Hole Center - Center (O.1) | 175 mm |
Mount Hole Center - Center (O.2) | 137 mm |
Mount Hole Center - Center (O.3) | 69 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 15 qty |
No./Teeth (Replaces) | 15 qty |
Pinion at Rest (B) | 67 mm |
Rotation | ACW |
Spigot Diameter (A) | 55 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LAND ROVER | Freelander 2.5 V6 | [25K4F] | 01.2000-12.2006 |
MG | ZT-T 160 2.5 | [25K4F] | 01.2001-12.2005 |
MG | ZT-T 190 2.5 | [25K4F] | 01.2001-12.2005 |
ROVER | 75 2.0 V6 | [20K4F] | 01.1999-12.2005 |
ROVER | 75 2.5 V6 | [25K4F] | 01.1999-12.2005 |
ROVER | 75 2.5 V6 | [KV6] | 01.1999-12.2005 |
Reference Information
LRS1542 22.1320M DSN603 JS1320 NAD100952E 22.132 8213230 STR6206 003-H207 MAV421620 S12DE0645 201320 LRS01542 3H207 25-3028 6040162 STRF187 12019 NAD100952L 220925 AEY1542 S12DE0645A2 PRSF187 SS663 GNU4821 228000-7710 20432261BN NAD100952 115950 17890R 8080206 3665 20432261OE CST40162GS 17890N CST40162AS MTH207Video/Publications
003-H207 115950 12019 17890N 201320 20432261BN 20432261OE 22.1320 22.1320M 228000-7710 25-3028 3665 3H207 6040162 8080206 8213230 AEY1542 CST40162AS CST40162GS DSN603 JS1320 LRS01542 LRS1542 MAV421620 MTH207 NAD100952 NAD100952L SS663 STRF187 220925Add Your Number
