Associated Numbers
028000-5300 028000-5301 110507 17286N 201231 20452106BN 20736 228000-5300 28000-5300 28100-77090 6044601 CST44601AS DRS3256 STR70270 UD11128S UNIT BOM 190-813
028000-5300
References:
JANNCO 410-52013R
Denso 028000-5300, 028000-5301
Lester 17286
PIC Picture ID 190-813
Toyota 28100-77090
snj009 70-8556
Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 298 mm |
Mount Hole Center - Center (O.1) | 111 mm |
Mount Hole Center - Center (O.2) | 111 mm |
Mount Hole Center - Center (O.3) | 135 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
Mount Hole Diameter (C.3) | 13 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 57 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | 2FD100 | [2D] | |
TOYOTA | 2FD115 | [2D] | |
TOYOTA | 2FD135 | [2D] | |
TOYOTA | 3FD. | [2D] | |
TOYOTA | FD100 | [2D] |
Reference Information
028000-5300 BOM 028000-5301 UNIT 28100-77090 228000-5300 110507 20736 28000-5300 201231 STR6030 6044601 2810076015 17286N STR70270 UD11128S CGB-25300 MAV466010 190-813 DRS3256 20452106BN CST44601ASVideo/Publications
028000-5300 028000-5301 110507 17286N 201231 20452106BN 20736 228000-5300 28100-77090 6044601 CGB-25300 CST44601AS DRS3256 MAV466010 STR70270 UD11128S UNIT BOM 190-813Add Your Number
