Associated Numbers
063280048010 0986023260 114056 190.560.092 201362 201362D 20432862 25-4071 28100-0D080 28100-0D090 28100-0D180 31346N 428000-0341 428000-0680 428000-4500 428000-7710 6040268 63280048 88212910 8EA012528-941 8EA738258-421 943213621010 944280801990 9715 AEY2399 CST40268 CST40268AS CST40268ES CST40268GS CST40268OS CST40268RS DENDSN920 DRS0347 DS1457 EAA-121136 JS1362 LRS02399 MRS80199 MS428000-0680 MSN8048 NEY2399 SG0987 STM571 STN1362 UD809835(DENSO)S snj214 dxs4050 70-8117 190.553.092.210 190.553.092.010 113271 0001107433 0001107434 190.553.092.280 20401052BN 20401052OE 25-4248 28100-0D030 28100-0D110 28100-0D130 28100-22040 28100-22041 3929 BOS0001107433 DRT1060 DT2170 F004A94434 LRS02576 LRS2576 UD18652SSpecifications
Kilowatt | 1.3 kW |
Length (L.1) | 190 mm |
Mount Hole Center - Center (O.1) | 115 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 15.5 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Avensis 1.6 VVTi | [3ZZ-FE] | 04.2003- |
TOYOTA | Avensis 1.8 | [1ZZ-FE] | 04.2003- |
TOYOTA | Corolla 1.6 Verso | [3ZZ-FE] | 04.2004- |
TOYOTA | Corolla 1.8 Verso | [1ZZ-FE] | 04.2004- |
TOYOTA | Corolla 1.8 Verso | 03.2004- | |
TOYOTA | Corolla 1.8 Verso | 09.2001-05.2004 |
Reference Information
201362D 20432862BN 31346N DSN920 EAA-121136 S12DE0136A2 201362 281000-D090 6040268 LRS02399 2810022031 28100-0D090 CST40268AS 2810022030 336072 201362M 428000-4500 20432862OE STR70583 STRS219 28100-0D130 PRSS219 63280048010 DENDSN920 MSN8048 DS1457 STM571 000986023260 220542 MS428000-0680 F042200010 281000D030 28100-22030 J5212122 2810022040 28100-0D180 STN1362 28100-22031 2810022041 3T385 SG0987 NEY2399 986023260 190.560.092.050 12052 9.44281E+11 UD809835(DENSO)S JS1362 190.560.092.058 MRS80199 190.560.092.059 28100-22040 CST40268GS 28100-0D030 28100-22041 428000-7710 428000-0680 114056 9715 000F042200010 CGB-54071 25-4071 8EA012528-941 88212910 LRS2399 190.560.092.260 MTT385 STR6413 MAV421610 281000D130 6040268.1 28100-0D080 446527 DRS0347 003-T385Video/Publications
063280048010 0986023260 114056 190.560.092 201362 201362D 20432862 25-4071 28100-0D080 28100-0D090 28100-0D180 31346N 428000-0341 428000-0680 428000-4500 428000-7710 6040268 88212910 8EA012528-941 8EA738258-421 943213621010 944280801990 9715 AEY2399 CST40268 CST40268AS CST40268ES CST40268GS CST40268OS CST40268RS DENDSN920 DRS0347 DS1457 EAA-121136 JS1362 LRS02399 LRS2399 MRS80199 MS428000-0680 MSN8048 NEY2399 SG0987 STM571 STN1362 UD809835(DENSO)S 220542Add Your Number
