Associated Numbers
101448 20432523BN 25-3458 28100-0L051 28100-54450 33287N 428000-2631 6040325 9755 AEY2480 CS1448 CST40325AS CST40325GS DRS0449 LRS02287 SS635 STR70343Specifications
Kilowatt | 2.7 kW |
Length (L.1) | 260 mm |
Mount Hole Center - Center (O.1) | 130 mm |
Mount Hole Diameter (C.1) | 14.5 mm |
Mount Hole Diameter (C.2) | M12x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 18 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Hi-Lux 2.5 D-4D | [2KD-FTV] | |
TOYOTA | Hi-Lux 2.5 D-4D 4WD | [2KD-FTV] |
Reference Information
SS635 986026030 28100-0L051 28100-0L052 28100-0L050 20432523OE 281000L05184 STR70343 20432523BN S6059 CST40325GS AI-80045 9755 324ST21 A79460 114853 CS1448 6040325 107260 DRS0449 DENDSN1371 DSN1371 428000-2632 8EA011612-431 428000-2633 6040325.1 428000-2630 101448D 428000-2631 LRS2287 3113900 12324 3113869 228000-2633 190.585.112.260 AZMT-53-010-1238 11040810 PRSS305 281000L05284 T521A36 ANM12669X WG1920083 CST40325AS WG2013525 TG4280002631 TT16447 TG4280002632 101448 AEY2480 190.585.112.050 2-0788 ST01489 281005-4450 335220112 WOOSTR70343 000986026030 28100-54451 28100-54450 STR6458 H5040561 28100-54491 33287N STRS305 10439432 S-70343 25-3458 LRS02287 428080-2633 190.585.112.058 SDN325A 88212548 S12DE0228A2 TO9079 5040561 220957AVideo/Publications
101448 114853 20432523BN 25-3458 28100-0L051 28100-54450 33287N 428000-2631 6040325 9755 AEY2480 CS1448 CST40325AS CST40325GS DRS0449 LRS02287 LRS2287 S6059 SS635 STR70343 STRS305Add Your Number
