Information
1280009190Associated Numbers
111682 11864 128000-8210 128000-9190 128000-9191 17423N 17524N 17524R 17681RW 2-1073-ND 201084 20432121BN 20510118 22.1084 25-1317 28100-76060 28100-76070 6040121 9837 AES1218 CST40121AS DRS3176 EAA-111776 JS1084 LRT00118 S1075R SS827 SS959 STR-8015 STR8015
16-965 16965
70-8457
SNJ029
dxs508
DXS515
0986UR1193 Bosch ruil
0986UR1217 Bosch ruil
1280008210 Denso show
190527093 PSH
2280002840 Denso
2280002841 Denso show
2280002852 Denso
2810076070 Toyota
458508 Valeo
9712809820 Denso
DRS3844 Remy
F042000145 Bosch
HJS1084 HC
JS1084 HC
LRT00118 Lucas
S26095 Hitachi
SR3234X Bosch (USA)
SR3260X Bosch (USA)
1280009190 Denso show
1280009191 Denso show
190944093 PSH
2280002831 Denso show
2280002832 Denso
2280002833 Denso
2280002834 Denso
251317 Elstock
252475 Elstock
2810076060 Toyota
2810076081 Toyota
2810076081R RNL
DRS3176 Remy
LRS01511 Lucas
RNL1280009190 RNL
STR70251 Wood Auto
STR8048 Wood Auto
WOOSTR70251 Wood Auto
0986019181 Bosch ruil
111556 Cargo
1280008200 Denso show
190945093 PSH
20510118 Prestolite
2280002850 Denso
2280002851 Denso show
2810076050 Toyota
2810076101 Toyota
2810076850 Toyota
569361 Valeo
894JSRH RNL
ATS320 ATK
DRS3387 Remy
DRS3388 Remy
HJC894 HC
JS894 HC
STR70242 Wood Auto
TRS098 TWA
WOOSTR70242 Wood Auto
Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 178 mm |
| Mount Hole Center - Center (O.1) | 93.5 mm |
| Mount Hole Center - Center (O.2) | 87 mm |
| Mount Hole Center - Center (O.3) | 118.5 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 19 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Previa 2.4 | [2TZ-FE] | 05.1990-08.2000 |
| TOYOTA | Previa 2.4 4WD | [2TZ-FE] | 05.1990-08.2000 |
| TOYOTA | Previa 2.4 DLX | [2TZ-FE] | 01.1991-01.1993 |
| TOYOTA | Previa 2.4 LE | [2TZ-FE] | 01.1991-01.1993 |
Reference Information
CST40121AS SS959 28100-76050 28100-76070 JS1084 9712809-820 STR6262 128000-9191 128000-9190 201084 6040121 STR-8015 111682 9837 CGB-23176 17524R 20510118 11864 2810076050 17524N 22.1084 LRT00118 MAV5860 17423N 20432121BN SS827 2-1073-ND STRF706 S1075R 281007060 25-1317 28100-76060 AES1218 17681RW STR6110 28100-76101 STX200893 STX200970 STR8015 9712809820 128000-8210 DRS3176Video/Publications
