Associated Numbers
101468 101468D 25-4085 31131N 428000-1940 428000-1941 428000-4880 AEY2413 DSN944 LRS02413 NAD500080 NAD500080E NAD500330 STR70280Specifications
Kilowatt | 2 kW |
Length (L.1) | 241 mm |
Mount Hole Center - Center (O.1) | 146 mm |
Mount Hole Center - Center (O.2) | 24 mm |
Mount Hole Center - Center (O.3) | 130 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | 11.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 25 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LAND ROVER | Discovery 2.7 TD | [276DT] | 01.2004-12.2009 |
LAND ROVER | Discovery 2.7 TD | [276DT] | 01.2009- |
LAND ROVER | Range Rover Sport 2.7 TDVM | [276DT] | 01.2005-12.2009 |
Reference Information
LRS2413 101468D 450.520.092 DSN944 STN9468 LR087021 220653 336555 428000-4880 LRS02413 STM1193 115642 428000-4881 DRS0055 STR70280 LR043962 986027080 101468 DS1165 6040318.1 NAD500080 000986027080 88212459 NAD500080E STR6182 S12DE0457A2 DENDSN944 12185 5H22-11002-AC 3178 5H22-11002-AD CS1468 J5210802 STN1468 31131N EAA-122036 8080344 LR039482 11040829 NAD500330 S12DE0457 25-4085 428000-1940 CST40318GS 20432813OE 428000-1941Video/Publications
0986027080 101468 101468D 11040829 115642 12185 20432813OE 220653 25-4085 31131N 3178 428000-1940 428000-1941 428000-4880 428000-4881 450.520.092 5H22-11002-AC 5H22-11002-AD 6040318.1 8080344 88212459 CS1468 CST40318GS DENDSN944 DRS0055 DS1165 EAA-122036 J5210802 LR039482 LR043962 LR087021 LRS02413 LRS2413 NAD500080 NAD500080E NAD500330 STM1193 STN1468 STN9468 STR70280Add Your Number
