Associated Numbers
20432882OE 25-4251 254581 254581D 28100-0N040 28100-33110 428000-6060 428000-6190 428000-6191 6040288 CST40288GS DSN945 EAA-121993 LRS02579 S6039 STR70333
11040828 EuroTec
115723 Cargo
12268 EAI
190594092 PSH
281000N040 Toyota
281000N04084 Toyota
281000N060 Toyota
2810033090 Toyota
2810033110 Toyota
4280006060 Denso
4280006061 Denso
4280006080 Denso
4280006190 Denso
4280006191 Denso
4280006220 Denso
4280006221 Denso
458859 Valeo
63280069 Magneti Marelli
63280069010 Magneti Marelli
8080338F Friesen
910522 EDR
9749 CEVAM
DRS0522 Remy
DSN945 Denso
LRS02579 Lucas
Specifications
| Kilowatt | 1 kW |
| Length (L.1) | 197 mm |
| Mount Hole Center - Center (O.1) | 121 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 14 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.4 D-4D | [1ND-TV] | 03.2007- |
| TOYOTA | Yaris 1.4 D-4D | [1ND-TV] | 01.2006- |
Reference Information
LRS2579 DSN945 28100-0N040 28100-33110 254581 115723 220676 CST40288GS 428000-6190 428000-6191 EAA-121993 RNL428000-6190 S12DE0139A2 428000-6060 6040288 190.594.092.050 STR70333 336551 190.594.092.058 254581D S6039 20432882OE 25-4251 LRS02579Video/Publications
115723 20432882OE 25-4251 254581 254581D 28100-0N040 28100-33110 428000-6060 428000-6190 428000-6191 6040288 CST40288GS DSN945 EAA-121993 LRS02579 LRS2579 RNL428000-6190 S6039 STR70333 220676Add Your Number
