Associated Numbers
201368 201368D 25-4014 428000-1630 428000-4810 5802AH 5802AJ 5802AX 5802FE 9649448380 AET1368 DSN942 JS1368 LRS02342Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 240 mm |
Mount Hole Center - Center (O.1) | 36 mm |
Mount Hole Center - Center (O.2) | 121 mm |
Mount Hole Center - Center (O.3) | 37 mm |
Mount Hole Center - Center (O.4) | 116 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 9.5 mm |
Mount Hole Diameter (C.3) | 9.5 mm |
Mount Hole Diameter (C.4) | 10.5 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 21 qty |
No./Teeth (Replaces) | 21 qty |
Pinion at Rest (B) | 7 mm |
Rotation | ACW |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CITROEN | C5 2.7 HDi | [DT17ED4] | 02.2008- |
CITROEN | C5 2.7 HDi | [UHZ(DT17BTED4)] | 02.2008- |
CITROEN | C6 2.7 HDi | [DT17TED4] | 09.2005-05.2008 |
PEUGEOT | 407 2.7 HDi | [DT17TED4] | 10.2005-07.2008 |
PEUGEOT | 607 2.7 HDi 24V | [DT17TED4] | 12.2004- |
Reference Information
5802AX JS1368 20432713OE DSN942 201368D 5802AP 20432713BN 6040317 5802AH 5802AJ 25-4014 S12DE0345 428000-1630 6040317.1 220801 9649448380 5702FE 201368 336521 STR6451 MAV423170A LRS02342 S12DE0345A2 33336N CST40317AS 5802FE CST40317GS 9664883081 428000-4810 5802FF 9638525380 9664883080 LRS2342 AET1368Video/Publications
201368 201368D 25-4014 428000-1630 428000-4810 5802AH 5802AJ 5802AX 5802FE 9649448380 AET1368 DSN942 JS1368 LRS02342 LRS2342 220801Add Your Number
