Associated Numbers
063280055010 0986023910 113314 12056 17806N 17806R 190.558.092 201224 201224D 201233 201233D 20510216 220926 228000-8550 25-3094 28100-21020 28100-21021 28100-21030 28100-21031 28100-21050 428000-7750 6044101 63280055 8212325 AES2216 CST44101 CST44101AS CST44101ES CST44101GS CST44101OS CST44101RS DENDSN934 DRS3866 DS4976 DSN934 J5212104 JS1224 LRT00216 MSN8055 SG0260 STM1224 STN1224 STR70291Specifications
Kilowatt | 1 kW |
Length (L.1) | 211 mm |
Mount Hole Center - Center (O.1) | 122 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 14 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Yaris 1.3 | [2NZ-FE] | 11.1995-10.2005 |
TOYOTA | Yaris 1.5 | [1NZ-FE] | 01.2003-11.2005 |
TOYOTA | Yaris 1.5 | [1NZ-FE] | 03.2000-07.2005 |
TOYOTA | Yaris 1.5 | [1NZ-FE] | 04.2001-09.2005 |
TOYOTA | Yaris Verso 1.3 | [2NZ-FE] | 08.1999-10.2002 |
TOYOTA | Yaris Verso 1.3 | [2NZ-FE] | 11.2002-09.2005 |
TOYOTA | Yaris Verso 1.5 | [1NZ-FE] | 03.2000-09.2005 |
Reference Information
DS4976 JS1224 3T356 201233D 28100-21050 003-T356 6044101 228000-8550 63280055010 LRT00216 CST44101ES 201224D SG0260 28100-21021 28100-21022 28100-21020 63280055 281002102 190.558.092 8212325 113314 17806R MSN8055 17806N AES2216 000986023910 DENDSN934 MTT356 STR6164 CST44101AS DRS3866 28100-21030 428000-7750 S12DE0226 28100-21031 2810021040 12056 CST44101RS 20510216 220926 DSN934 CST44101OS 28100-0M051 220486 201224 986023910 CST44101 CST44101GS STN1224 J5212104 201233 25-3094 STR70291 S12DE0226A2 STM1224Video/Publications
003-T356 063280055010 0986023910 113314 12056 17806N 17806R 190.558.092 201224 201224D 201233 201233D 20510216 220926 228000-8550 25-3094 28100-21020 28100-21021 28100-21030 28100-21031 28100-21050 3T356 428000-7750 6044101 8212325 AES2216 CST44101 CST44101AS CST44101ES CST44101GS CST44101OS CST44101RS DENDSN934 DRS3866 DS4976 J5212104 JS1224 LRT00216 MSN8055 MTT356 SG0260 STM1224 STN1224 STR70291 220486Add Your Number
