Associated Numbers
113244 201302 228000-6270 228000-6271 228000-6272 228000-6273 228000-9600 25-3206 28100-28010 28100-74270 428000-7770 AET1302 DSN922 JS1302 LRS01660 STR70253Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 207 mm |
Mount Hole Center - Center (O.1) | 122 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
No./Teeth (Replaces) | 13 qty |
Pinion at Rest (B) | 66 mm |
Rotation | ACW |
Spigot Diameter (A) | 55 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Avensis 2.0 i 16V | [1AZ-FSE] | 07.2000-01.2003 |
TOYOTA | Avensis 2.0 VVTi Verso | [1AZ-FE] | 05.2001-07.2005 |
TOYOTA | Avensis 2.4 WTi Verso GLS | [2AZ-FE] | 10.2003- |
TOYOTA | Camry 2.2 | [5S-FE] | 08.1996-09.2001 |
TOYOTA | Previa 2.4 16V | [2AZ-FE] | 08.2000- |
TOYOTA | RAV4 2.0 i 16V 4WD | [1AZ-FE] | 06.2000- |
TOYOTA | RAV4 2.0 VVT-i | [1AZFE] | 11.2005- |
Reference Information
JS1302 DSN922 6040238.1 PRSS961 28100-74270 228000-9600 312024 STN4302 428000-7770 LRS01660 MAV422380 190.557.132.260 25-3206 8EA738095-001 DRT0631 DENDSN922 MAV422380A STRS961U 228000-9210 CST40238GS STR6311 28100-28010 2810074240 17777N LRS1660 STM681 6040238 228000-6270 228000-6271 S12DE0586A2 S12DE0586 228000-6272 228000-6273 12057 88212556 28100-28020 8EA011610-751 2810003090 220485 PRSS961U 20432832BN 220487 STN1302 DT1741 190.557.132.050 J5212100 2810074140 CST40238AS STR70253 20432832OEVideo/Publications
12057 17777N 190.557.132.050 190.557.132.260 20432832BN 20432832OE 220487 228000-6270 228000-6271 228000-6272 228000-6273 228000-9210 228000-9600 25-3206 28100-28010 28100-28020 28100-74270 312024 428000-7770 6040238.0 6040238.1 88212556 8EA011610-751 8EA738095-001 CST40238AS CST40238GS DENDSN922 DRT0631 DT1741 J5212100 JS1302 LRS01660 LRS1660 MAV422380 MAV422380A PRSS961 PRSS961U STM681 STN1302 STN4302 STR70253 STRS961U 220485Add Your Number
