Associated Numbers
028000-9140 028000-9141 028000-9142 0330-402-0010 0330-402-0011 0330-402-0012 0330-402-0310 0330-402-0311 0330-402-0320 0350-552-0014 0350-552-0061 20432906BN 254462 28100-1090 28100-1090B 28100-1090C 28100-1442 28100-1443 6040609 CST40609AS EH700 STR70273Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 296 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Center - Center (O.2) | 138 mm |
Mount Hole Center - Center (O.3) | 119 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 27 mm |
Rotation | CW |
Spigot Diameter (A) | 100 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HINO | Various Models | 01.1984- |
Reference Information
28100-1090C 28100-1090B 20432906BN 0350-552-0061 6040609 254462 28100-1443 28100-1442 028000-9140 28100-1090 CST40609AS STR6851 0330-402-0011 0330-402-0012 0330-402-0320 EH700 028000-9141 0330-402-0310 028000-9142 0330-402-0311 STR70273 0330-402-0010Video/Publications
028000-9140 028000-9141 028000-9142 0330-402-0010 0330-402-0011 0330-402-0012 0330-402-0310 0330-402-0311 0330-402-0320 0350-552-0061 20432906BN 254462 28100-1090 28100-1090B 28100-1090C 28100-1442 28100-1443 6040609 CST40609AS EH700 STR70273Add Your Number
