- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
101292 101292D 112823 20432006BN 20432006OE 20540101 228000-7550 28.1292 28.1292M 2995988 32958N 42.498.115 45-3261 5801710983 6040600 7.61003 8094 88213096 8880220 8EA738152-001 99486046 AEY1958 CS1292 CST40600AS CST40600GS DRS3897 DSN940 EAA-121095 F042000242 G201292D-R GSDSN940-A LRS01958 MS198 RNL1292CS S6005 STR70278Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 317 mm |
Mount Hole Center - Center (O.1) | 125 mm |
Mount Hole Center - Center (O.2) | 125 mm |
Mount Hole Center - Center (O.3) | 125 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
Mount Hole Diameter (C.3) | 13 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 49 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | DENSO |
Voltage | 24 V |
Wet Clutch | Yes |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
IVECO | 190 E 38 12.9 | (Cursor)[F3BE0681G] | 08.2000- |
IVECO | 190 E 39 10.3 | [F3AE0681E] | 11.1999- |
IVECO | 190 E 39 10.3 | [F3AE0681E] | 11.1999-02.2002 |
IVECO | 190 E 43 10.3 | [F3AE0681D] | 01.2001- |
IVECO | 190 E 43 10.3 | [F3AE0681D] | 11.1999-02.2002 |
IVECO | 190 E 44 12.9 | (Cursor)[F3BE0681C] | 08.2000- |
IVECO | 190 S 40 10.3 | [F3AE0681B] | 02.2002- |
IVECO | 190 S 43 10.3 | [F3AE0681D] | 02.2002- |
IVECO | 190 S 48 12.9 | [F3BE0681E] | 02.2002- |
IVECO | 260 E 38 12.9 | (Cursor)[F3BE0681G] | 08.2000- |
IVECO | 260 E 39 10.3 | [F3AE0681E] | 11.1999- |
IVECO | 260 E 39 10.3 | [F3AE0681E] | 11.1999-02.2002 |
IVECO | 260 E 40 10.3 | [F3AE0681B] | 08.2001-09.2004 |
IVECO | 260 E 43 10.3 | [F3AE0681D] | 11.1999- |
IVECO | 260 E 43 10.3 | [F3AE0681D] | 11.1999-02.2002 |
IVECO | 260 E 44 12.9 | (Cursor)[F3BE0681C] | 08.2000- |
IVECO | 260 S 40 10.3 | (Cursor)[F3AE0681B] | 02.2002- |
IVECO | 260 S 43 10.3 | (Cursor)[F3AE0681D] | 02.2002- |
IVECO | 260 S 48 12.9 | (Cursor)[F3BE0681E][F3BE0681E] | 02.2002- |
IVECO | 260 S 54 12.9 | (Cursor)[F3BE0681A][F3BE0681A] | 02.2002- |
IVECO | 340 E 38 12.9 | (Cursor)[F3BE0681G] | 08.2000- |
IVECO | 340 E 44 12.9 | (Cursor)[F3BE0681C] | 08.2000- |
IVECO | 380 E 38 12.9 | (Cursor)[F3BE0681G] | 08.2000-08.2004 |
IVECO | 380 E 44 12.9 | (Cursor)[F3BE0681C] | 08.2000-11.2004 |
IVECO | 410 E 38 12.9 | (Cursor)[F3BE0681G] | 08.2000- |
IVECO | 410 E 44 12.9 | (Cursor)[F3BE0681C] | 08.2000-08.2004 |
IVECO | 440 E 39 10.3 | [F3AE0681E] | 11.1999- |
IVECO | 440 E 40 10.3 | [F3AE0681B] | 08.2001-09.2004 |
IVECO | 440 E 43 10.3 | [F3AE0681D] | 11.1999- |
IVECO | 440 E 43 10.3 | [F3AE0681D] | 11.1999-02.2002 |
IVECO | 440 E 48 12.9 | [F3BE0681E] | 08.2000-08.2003 |
IVECO | 440 S 40 10.3 | (Cursor)[F3AE0681B] | 02.2002- |
IVECO | 440 S 43 10.3 | (Cursor)[F3AE0681D] | 02.2002- |
IVECO | 440 S 48 12.9 | (Cursor)[F3BE0681E][F3BE0681E] | 02.2002- |
IVECO | 440 S 54 12.9 | [F3BE0681A] | 02.2002- |
Reference Information
2995988 EAA-121095 28.1292 8094 11.139.170 CST40600AS ANM16117 STRL062 501.503.103.260 20540101 0001986S10107 CS1292 5801710983 AZG4878 CGB-23897 501.503.103.265 RNL1292CS 7.61003 1986S10107 PRSL062 6040600 3957597 99486046 AEY1958 STR70278 336265 228000-7551 228000-7550 115872 LRS1958 S6005 112823 101292 88213096 20432006OE 000986023430 MAV5890 CST40600GS 220210 DSN940 MS198 28.1292M S24DE0046A2 5802918519 GSDSN940-A 47435950 20432006BN 58017010983 STN1292 5801711014 000F042000242 IS9154 STR6160 6040600.1 8880220 45-3261 63207140010 986023430 F042000242 72497287 MAV5890A 801710983 32958N 228000-7650 501.503.103.050 504106753 8EA738152-001 MNS247 DRS3897 SG0244 LRS01958 G201292D-R 228080-7550 42.498.115 501.503.103.058 19085003 438477Video/Publications
101292 101292D 112823 20432006BN 20432006OE 20540101 228000-7550 28.1292 28.1292M 2995988 32958N 42.498.115 45-3261 5801710983 6040600 7.61003 8094 88213096 8880220 8EA738152-001 99486046 AEY1958 CGB-23897 CS1292 CST40600AS CST40600GS DRS3897 DSN940 EAA-121095 F042000242 G201292D-R GSDSN940-A LRS01958 LRS1958 MAV5890 MS198 RNL1292CS S6005 STR70278 STRL062 220210Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
