Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 451.64 including GST
NZ$ 392.73 excluding GST
or four payments of $112.91
with
Learn More
each
S6003
No stock in NZ currently
No stock in NZ currently
Associated Numbers
028000-5880 028000-5881 028000-5882 028000-5883 028000-5884 110627 16658N 2-1726-ND 201012 20432051BN 25-1436 35259620 6040150 8499 88212417 8EA737266-001 AEY1256 CST40150 CST40150AS CST40150ES CST40150GS CST40150OS CST40150RS DRS3539 EAA-121754 JS1012 LRS01256 STN1012 STR70081Specifications
| Kilowatt | 2.50 kW |
| Length (L.1) | 293 mm |
| Mount Hole Center - Center (O.1) | 89 mm |
| Mount Hole Center - Center (O.2) | 89 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| OEM Product | No |
| Pinion at Rest (B) | 48 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 450 C | 01.1989-01.1994 | |
| CASE | 480 CK | 01.1989-01.1994 | |
| CASE | 580 | 01.1982-01.1994 | |
| CASE | 580 C | [188D] | 01.1975-12.1980 |
| CASE | 580 C | [207D] | 01.1975-12.1980 |
| CASE | 580 D | [188D] | 01.1980-12.1983 |
| CASE | 580 D | [207D] | 01.1980-12.1983 |
Reference Information
| 028000-5880 | DENSO |
| 028000-5881 | DENSO |
| 028000-5882 | DENSO |
| 028000-5883 | DENSO |
| 028000-5884 | DENSO |
| 110627 | CARGO |
| 116930A1 | CASE |
| 16658N | WAI / TRANSPO |
| 201012 | KUHNER |
| 20432051BN | REAL |
| 2-1726-ND | WAI / TRANSPO |
| 25-1436 | ELSTOCK |
| 335862 | LOGISTIK |
| 35259620 | PRESTOLITE |
| 6040150 | SANDO |
| 8499 | CEVAM |
| 88212417 | POWERMAX |
| 8EA737266-001 | HELLA |
| AEY1256 | AUTOELECTRO |
| CGB-23539 | AINDE |
| CST40150 | CASCO |
| CST40150AS | CASCO |
| CST40150ES | CASCO |
| CST40150GS | CASCO |
| CST40150OS | CASCO |
| CST40150RS | CASCO |
| DRS3539 | DELCO |
| F032110627 | CARGO |
| JS1012 | HC PARTS |
| LRS01256 | LUCAS |
| LRS1256 | LUCAS |
| MAV421500 | SIOM |
| R39341 | CASE |
| STN1012 | KRAUF |
| STR6166 | ELECTROLOG |
| STR70081 | WOODAUTO |
| STRW060 | 3EFFE |
