Associated Numbers
M0T35274 UD20426S 92180353 92182365 92190142 92204529 STM5274 M0T35272 M0T35273
S5390S S5405S S5480S 410-48302
Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 193 mm |
Mount Hole Center - Center (O.1) | 23 mm |
Mount Hole Center - Center (O.2) | 83 mm |
Mount Hole Center - Center (O.3) | 97 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 68 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Caprice 3.6 V6 | [VZHF] | 01.2005-12.2005 |
Alternatives >>>
S5390S - with push on lucar terminal for exciter/switch connection
S5405S - with 5mm stud connection for exciter/switch
S5480S - with push on lucar terminal for exciter/switch connection - 1.4kW version
410-48302 - with bespoke connector for exciter/switch connection
Reference Information
92190142 92180353 UD20426S 92182365 STM5274 92204529 M0T35274 M0T35276 M0T35273Video/Publications
92180353 92182365 92190142 92204529 M0T35273 M0T35274 M0T35276 STM5274 UD20426SAdd Your Number
