Associated Numbers
150.515.102 20437972OE 20437972RC 25-3006 32328N 6035279.2 CST35279RS DRS0011 LRS01529 M002T63271 M2T63271 ME200206 STR71000 UD11143S
M8T71071 MXS244 70-6583 snj553 snj517gq
M8T71071zt
Bosch 0986020421, 0986022700 Cargo 112370 CAS CST35113AS Delco DRS3863N HC-PARTS JS1221 HELLA 8EA011610671, 8EA737881001 KRAUF STM1221BA, STM1221LC, STM1221NL, STM1221TJ, STM1221WD, STM1221WL, STM1221XY, STM1221YJ, STM5225LC, STM5225RD, STM5225WD, STM5225XY, STM5225YJ Messmer 220115 Mitsubishi 1810A050, M008T71071, M008T75071, M008T75071A, M008T75073, M008T75073A, M008T75074, M2T63271, M8T71071, M8T75071, M8T75071A, M8T75073, M8T75073A, M8T75074, M8T75871, ME200206, ME201650, ME202424, ME202970, ME204423, ME204424, ME204425, RE204424C Motorherz STM1221RB, STM1221WA, STM5225WA SAE S122J005 Unipoint STR7030, STR7030A WAI 2-3205-MI, 2-3216-2W WPS 32328N ZAUFER 300N10054Z
150925102 PSH
M008T71071 Mitsubishi
M008T71071A Mitsubishi
M8T71071 Mitsubishi
M8T71071A Mitsubishi
M8T71071AM Mitsubishi
ME204423 Mitsubishi
Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 240 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 8.5 mm |
Rotation | CW |
Spigot Diameter (A) | 77 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Pajero 2.8 TD | [4M40-T] | 06.1994-10.1999 |
MITSUBISHI | Pajero 3.2 Di-D | [4M41] | 02.2007- |
MITSUBISHI | Pajero 3.2 Di-D | [4M41] | 04.2000-10.2001 |
MITSUBISHI | Pajero 3.2 Di-D | [4M41] | 04.2000-12.2006 |
MITSUBISHI | Pajero 3.2 Di-D | [4M41] | 10.2001-12.2006 |
MITSUBISHI | Pajero 3.2 Di-D 4WD | [4M41] | 01.2009- |
MITSUBISHI | Pajero 3.2 Di-D 4WD | [4M41] | 02.2007- |
Reference Information
5035733 UD11143S S5399S 32328N ME200206 220115 336228 20437972OE S12MH0211A2 25-3006 LRS1529 ANM12231X DRS0011 LRS01529 MTC129 MAV371130 M002T63271 3C129 STR5048 003-C129 6035279.2 220468 150.515.102 20437972RC J5215039 CGB-23022 M2T63271 CST35279RS STR71000 STM2014Video/Publications
003-C129 150.515.102 20437972OE 20437972RC 25-3006 32328N 3C129 6035279.2 CGB-23022 CST35279RS DRS0011 J5215039 LRS01529 LRS1529 M002T63271 M2T63271 MAV371130 ME200206 MTC129 STR71000 UD11143S 220115 220468Add Your Number
