Associated Numbers
12196 160.574.132 17863N 20437041 23300-CA000 23300-CA000A 25-3419 256080 6035140 91-27-3331 AEY2248 CST35140 CST35140AS CST35140ES CST35140GS CST35140OS CST35140RS DRS0102 DS1212 EAA-123190 J5211095 LRS02248 M001T68681 M001T68681ZC M1T68681 M1T68681ZC S-80071 STM3668 STR71084 UD20456S 23300CA00ASpecifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 224 mm |
| Mount Hole Center - Center (O.1) | 92 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 51.5 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | Murano 3.5 | [VQ35DE] | 01.2004-12.2008 |
| NISSAN | Teana 3.5 | [VQ35DE] | 01.2003-12.2008 |
Reference Information
M1T68681ZC STRW395 M001T68681 M001T68681ZC S-80071 12196 AEY2248 CST35140RS 3D224 003-D224 UD20456S ANM12322X 20437041 STM3668 17863N LRS2248 23300-CA000A 256080 DS1212 25-3419 23300CA00A M1T68681 CST35140OS 6035140 CST35140ES LRS02248 MTD224 CST35140 DRS0102 160.574.132 CST35140GS EAA-123190 J5211095 STR71084 23300-CA000 91-27-3331 CST35140AS STR5280Video/Publications
003-D224 12196 160.574.132 17863N 20437041 23300-CA000 23300-CA000A 25-3419 256080 3D224 6035140 91-27-3331 AEY2248 CST35140 CST35140AS CST35140ES CST35140GS CST35140OS CST35140RS DRS0102 DS1212 EAA-123190 J5211095 LRS02248 LRS2248 M001T68681 M001T68681ZC M1T68681 M1T68681ZC MTD224 S-80071 STM3668 STR71084 STRW395 UD20456SAdd Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
