Associated Numbers
12196 160.574.132 17863N 20437041 23300-CA000 23300-CA000A 25-3419 256080 6035140 91-27-3331 AEY2248 CST35140 CST35140AS CST35140ES CST35140GS CST35140OS CST35140RS DRS0102 DS1212 EAA-123190 J5211095 LRS02248 M001T68681 M001T68681ZC M1T68681 M1T68681ZC S-80071 STM3668 STR71084 UD20456S 23300CA00ASpecifications
Kilowatt | 1.7 kW |
Length (L.1) | 224 mm |
Mount Hole Center - Center (O.1) | 92 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 51.5 mm |
Rotation | ACW |
Spigot Diameter (A) | 75 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Murano 3.5 | [VQ35DE] | 01.2004-12.2008 |
NISSAN | Teana 3.5 | [VQ35DE] | 01.2003-12.2008 |
Reference Information
M1T68681ZC STRW395 M001T68681 M001T68681ZC S-80071 12196 AEY2248 CST35140RS 3D224 003-D224 UD20456S ANM12322X 20437041 STM3668 17863N LRS2248 23300-CA000A 256080 DS1212 25-3419 23300CA00A M1T68681 CST35140OS 6035140 CST35140ES LRS02248 MTD224 CST35140 DRS0102 160.574.132 CST35140GS EAA-123190 J5211095 STR71084 23300-CA000 91-27-3331 CST35140AS STR5280Video/Publications
003-D224 12196 160.574.132 17863N 20437041 23300-CA000 23300-CA000A 25-3419 256080 3D224 6035140 91-27-3331 AEY2248 CST35140 CST35140AS CST35140ES CST35140GS CST35140OS CST35140RS DRS0102 DS1212 EAA-123190 J5211095 LRS02248 LRS2248 M001T68681 M001T68681ZC M1T68681 M1T68681ZC MTD224 S-80071 STM3668 STR71084 STRW395 UD20456SAdd Your Number
