Associated Numbers
17964N 255246 31200-RJE-A01 91-27-3368 M000R15571ZC M000T15571 M000T15571ZC M0R15571ZC M0T15571 M0T15571ZC MHG024 S-80346 STM4071 UD20410SSpecifications
Kilowatt | 1.6 kW |
Length (L.1) | 223 mm |
Mount Hole Center - Center (O.1) | 109 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 19 qty |
Pinion at Rest (B) | 15 mm |
Rotation | ACW |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Pilot 3.5 | 01.2006-12.2008 | |
HONDA | Ridgeline 3.5 | 01.2006-12.2008 |
Reference Information
17964N M000T15571 M000T15571ZC M0T15571 STM4071 255246 M000R15571ZC 31200-RJE-A01 M0R15571ZC M0T15571ZC UD20410S S-80346 91-27-3368 MHG024Video/Publications
17964N 255246 31200-RJE-A01 91-27-3368 M000R15571ZC M000T15571 M000T15571ZC M0R15571ZC M0T15571 M0T15571ZC MHG024 S-80346 STM4071 UD20410SAdd Your Number
