S5301S - Brand new AS-PL Starter motor

Specifications

Kilowatt	5.5 kW
Length (L.1)	318 mm
Mount Hole Center - Center (O.1)	129 mm
Mount Hole Center - Center (O.2)	88 mm
Mount Hole Center - Center (O.3)	144 mm
Mount Hole Diameter (C.1)	13.5 mm
Mount Hole Diameter (C.2)	13.5 mm
Mount Hole Diameter (C.3)	13.5 mm
No./Mount holes	3 qty
No./Mount holes with thread	0 qty
No./Teeth	12 qty
Pinion at Rest (B)	47 mm
Rotation	CW
Spigot Diameter (A)	92 mm
Unit Type	MITSUBISHI
Voltage	24 V

Vehicle Applications

Make	Model	Type	Year
MAN	26.320 10.5	[D2066LF28]	10.2007-
MAN	26.320 10.5	[D2066LF39]	07.2008-
MAN	26.320 10.5	[D2066LF39]	10.2007-
MAN	26.320 10.5	[D2066LF43]	07.2008-
MAN	26.320 10.5	[D2066LF43]	10.2007-
MAN	26.320 10.5	[D2066LF53]	07.2008-
MAN	26.320 10.5	[D2066LF68]	07.2008-
MAN	26.360 10.5	[D2066LF38]	08.2008-
MAN	26.360 10.5	[D2066LF42]	10.2007-
MAN	26.360 10.5	[D2066LF48]	08.2008-
MAN	26.360 10.5	[D2066LF52]	08.2008-
MAN	26.360 10.5	[D2066LF64]	08.2008-
MAN	26.360 10.5	[D2066LF64]	10.2007-
MAN	26.360 10.5	[D2066LF67]	08.2008-
MAN	26.360 10.5	[D2066LF67]	10.2007-
MAN	26.390 10.5	[D2066LF02]	02.2004-
MAN	26.390 10.5	[D2066LF02]	05.2004-
MAN	26.390 10.5	[D2066LF02]	06.2005-
MAN	26.390 10.5	[D2066LF02]	07.2005-
MAN	26.390 10.5	[D2066LF12]	02.2004-
MAN	26.390 10.5	[D2066LF12]	05.2004-
MAN	26.390 10.5	[D2066LF12]	06.2005-
MAN	26.390 10.5	[D2066LF24]	05.2004-
MAN	26.390 10.5	[D2066LF32]	05.2004-
MAN	26.390 10.5	[D2066LF32]	06.2005-
MAN	26.390 10.5	[D2066LF37]	02.2004-
MAN	26.390 10.5	[D2066LF37]	05.2004-
MAN	26.390 10.5	[D2066LF37]	06.2005-
MAN	26.400 10.5	[D2066LF02]	02.2004-
MAN	26.400 10.5	[D2066LF02]	05.2004-
MAN	26.400 10.5	[D2066LF02]	06.2005-
MAN	26.400 10.5	[D2066LF06]	05.2004-
MAN	26.400 10.5	[D2066LF12]	02.2004-
MAN	26.400 10.5	[D2066LF12]	05.2004-
MAN	26.400 10.5	[D2066LF12]	06.2005-
MAN	26.400 10.5	[D2066LF26]	05.2004-
MAN	26.400 10.5	[D2066LF26]	10.2007-
MAN	26.400 10.5	[D2066LF32]	02.2004-
MAN	26.400 10.5	[D2066LF32]	05.2004-
MAN	26.400 10.5	[D2066LF32]	06.2005-
MAN	26.400 10.5	[D2066LF37]	02.2009-
MAN	26.400 10.5	[D2066LF37]	05.2004-
MAN	26.400 10.5	[D2066LF37]	06.2005-
MAN	26.400 10.5	[D2066LF41]	02.2009-
MAN	26.400 10.5	[D2066LF41]	10.2007-
MAN	26.400 10.5	[D2066LF49]	02.2009-
MAN	26.400 10.5	[D2066LF51]	02.2009-
MAN	26.400 10.5	[D2066LF61]	02.2009-
MAN	26.400 10.5	[D2066LF61]	10.2007-
MAN	26.400 10.5	[D2066LF63]	02.2009-
MAN	26.400 10.5	[D2066LF63]	10.2007-
MAN	26.440 10.5	[D2066LF25]	10.2007-
MAN	26.440 10.5	[D2066LF36]	02.2009-
MAN	26.440 10.5	[D2066LF36]	10.2007-
MAN	26.440 10.5	[D2066LF40]	02.2009-
MAN	26.440 10.5	[D2066LF40]	10.2007-
MAN	26.440 10.5	[D2066LF50]	02.2009-
MAN	26.440 10.5	[D2066LF50]	10.2007-
MAN	26.440 10.5	[D2066LF62]	02.2009-
MAN	26.440 10.5	[D2066LF62]	10.2007-
MAN	26.440 12.4	[D2676LF22]	10.2007-
MAN	26.440 12.4	[D2676LF22]	10.2012-
MAN	26.440 12.4	[D2676LF26]	10.2007-
MAN	26.440 12.4	[D2676LF26]	10.2012-
MAN	26.480 12.4	[D2676LF02]	02.2009-
MAN	26.480 12.4	[D2676LF02]	10.2007-
MAN	26.480 12.4	[D2676LF05]	02.2009-
MAN	26.480 12.4	[D2676LF05]	10.2007-
MAN	26.480 12.4	[D2676LF07]	02.2009-
MAN	26.480 12.4	[D2676LF07]	10.2007-
MAN	26.480 12.4	[D2676LF14]	10.2007-
MAN	26.480 12.4	[D2676LF20]	02.2009-
MAN	26.480 12.4	[D2676LF20]	10.2007-
MAN	26.480 12.4	[D2676LF25]	02.2009-
MAN	26.480 12.4	[D2676LF25]	10.2007-
MAN	26.540 12.4	[D2676LF06]	02.2009-
MAN	26.540 12.4	[D2676LF06]	10.2007-
MAN	26.540 12.4	[D2676LF13]	08.2006-
MAN	26.540 12.4	[D2676LF13]	10.2007-
MAN	28.320 10.5	[D2066LF39]	07.2008-
MAN	28.320 10.5	[D2066LF43]	07.2008-
MAN	28.320 10.5	[D2066LF68]	07.2008-
MAN	28.360 10.5	[D2066LF38]	08.2008-
MAN	28.360 10.5	[D2066LF42]	08.2008-
MAN	28.360 10.5	[D2066LF48]	08.2008-
MAN	28.360 10.5	[D2066LF64]	08.2008-
MAN	28.360 10.5	[D2066LF67]	08.2008-
MAN	28.400 10.5	[D2066LF37]	08.2008-
MAN	28.400 10.5	[D2066LF41]	08.2008-
MAN	28.400 10.5	[D2066LF49]	08.2008-
MAN	28.400 10.5	[D2066LF61]	08.2008-
MAN	28.400 10.5	[D2066LF63]	08.2008-
MAN	28.440 10.5	[D2066LF36]	08.2008-
MAN	28.440 10.5	[D2066LF40]	08.2008-
MAN	28.440 10.5	[D2066LF50]	08.2008-
MAN	28.440 10.5	[D2066LF62]	08.2008-
MAN	28.480 12.4	[D2676LF02]	08.2008-
MAN	28.480 12.4	[D2676LF05]	08.2008-
MAN	28.480 12.4	[D2676LF07]	08.2008-
MAN	28.480 12.4	[D2676LF20]	08.2008-
MAN	28.480 12.4	[D2676LF25]	08.2008-
MAN	32.390 10.5	[D2066LF02]	05.2004-
MAN	32.390 10.5	[D2066LF12]	05.2004-
MAN	32.390 10.5	[D2066LF37]	05.2004-
MAN	32.400 10.5	[D2066LF02]	05.2004-
MAN	32.400 10.5	[D2066LF12]	05.2004-
MAN	32.400 10.5	[D2066LF32]	05.2004-
MAN	37.390 10.5	[D2066LF02]	12.2004-
MAN	37.390 10.5	[D2066LF12]	12.2004-
MAN	37.390 10.5	[D2066LF32]	12.2004-
MAN	37.400 10.5	[D2066LF02]	12.2004-
MAN	37.400 10.5	[D2066LF12]	12.2004-
MAN	37.400 10.5	[D2066LF32]	12.2004-
MAN	400 10.5	[D2066LOH32]	10.2015-
MAN	440 12.4	[D2676LOH30]	10.2015-
MAN	C 440 12.4	[D2676LOH30]	10.2015-
MAN	C 480 12.4	[D2676LOH31]	10.2015-
MAN	L 440 12.4	[D2676LOH30]	10.2015-
MAN	L 480 12.4	[D2676LOH31]	10.2015-

Reference Information

S5301S LRS04121 CST35666AS M9T65571 336567 551.541.123 STM5571 STR71315 DS2096 000986025280 255252M CST35666RS M9TD1271 UD15155S 986025280 STRF005 45-5284 CST35666 M009TD1271 51.26201-7238 M9T65571AM 255252 M009T65571AM 116087 CST35666GS 130-90171 DRS0986 CST35666ES STR5463 M9TD1271AM 51.26201-9238 MITM9T65571 CST35666OS M009T65571 LRS4121 6035666 30321N

Video/Publications

0986025280 116087 130-90171 255252 255252M 30321N 45-5284 51.26201-7238 51.26201-9238 551.541.123 6035666 CST35666 CST35666AS CST35666ES CST35666GS CST35666OS CST35666RS DRS0986 DS2096 LRS04121 LRS4121 M009T65571 M9T65571 MITM9T65571 S5301S STM5571 STR71315 STRF005 UD15155S
