S5291PR - Remanufactured AS-PL Starter motor

Name: Remanufactured AS-PL Starter motor
Brand: AS-PL
SKU: S5291PR
Price: 273.24 NZD
Availability: InStock

Remanufactured AS-PL Starter motor

PREMIUM LINE

Manufacturer:

AS-PL

Replacement For:

MITSUBISHI

Price:

NZ$ 273.24 including GST

NZ$ 237.60 excluding GST

UOM:

each

Product Code:

S5291PR

Quantity In Stock Nationally:

No stock in NZ

Availability:

Item available to backorder, submit your order. Aprox 7-14 day delay - $40 Air freight charge additional

Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications
Add Your Number

101329M 101329V 220.524.113 28100-YV020 5802AA 5802EG 5802Z8 5802Z9 5802ZB 6035246 9645100680 96628540080 9663528880 966352888001 9801667780 980166778000 CST35246 CST35246AS CST35246ES CST35246GS CST35246OS CST35246RS D7G3 EAA-141374 M000R22471AM M000T2243 M000T22471 M000T22471AM M000T22472 M000T22472AM M000T22473 M000T22473AM M000T22473ZZ9 M0R22471AM M0T2243 M0T22471 M0T22471AM M0T22472 M0T22472AM M0T22473 M0T22473AM M0T22473ZZ9 MITM0T22473 STM1329 STV1329 STV9329 TS18E013 TS18E13

Kilowatt	1.5 kW
Length (L.1)	198 mm
Mount Hole Center - Center (O.1)	124 mm
Mount Hole Center - Center (O.2)	31 mm
Mount Hole Center - Center (O.3)	46 mm
Mount Hole Center - Center (O.4)	92 mm
Mount Hole Diameter (C.1)	9 mm
Mount Hole Diameter (C.2)	M8x1.25 mm
Mount Hole Diameter (C.3)	M8x1.25 mm
Mount Hole Diameter (C.4)	9 mm
No./Mount holes	4 qty
No./Mount holes with thread	2 qty
No./Teeth	12 qty
Pinion at Rest (B)	14 mm
Rotation	CW
Spigot Diameter (A)	65.5 mm
Unit Type	MITSUBISHI
Voltage	12 V

Make	Model	Type	Year
CITROEN	Berlingo 1.6 HDi 110	[9HL(DV6C)]	07.2010-
CITROEN	Berlingo 1.6 HDi 110	[9HR(DV6C)]	07.2010-
CITROEN	C1 1.4 HDi	[8HT(DV4TD)]	06.2005-09.2014
CITROEN	C2 1.4 HDi	[8HX(DV4TD)]	09.2003-
CITROEN	C2 1.4 HDi	[8HZ(DV4TD)]	09.2003-
CITROEN	C3 1.4 16V HDi	[8HY(DV4TED4)]	02.2002-
CITROEN	C3 1.4 HDi	[8HX(DV4TD)]	02.2002-
CITROEN	C3 1.4 HDi	[8HZ(DV4TD)]	02.2002-
CITROEN	C3 1.4 HDi 70	[8HR(DV4C)]	11.2009-
CITROEN	C3 1.4 HDi 70	[8HZ(DV4TD)]	11.2009-
CITROEN	C3 1.6 16V HDi	[9HX(DV6ATED4)]	10.2005-
CITROEN	C3 1.6 16V HDi	[9HZ(DV6TED4)	09.2005-
CITROEN	C3 Picasso 1.6 HDi	[9HX(DV6ATED4)]	02.2009-
CITROEN	C3 Picasso 1.6 HDi	[9HZ(DV6TED4)]	02.2009-
CITROEN	C3 Pluriel 1.4 HDi	[8HX(DV4TD)]	04.2004-
CITROEN	C4 1.6 HDi	[9HX(DV6ATED4)]	11.2004-07.2011
CITROEN	C4 1.6 HDi	[9HY(DV6TED4)]	11.2004-07.2011
CITROEN	C4 1.6 HDi	[9HZ(DV6TED4)]	11.2004-07.2011
CITROEN	C4 1.6 HDi	[9HZ(DV6TED4]	11.2004-07.2011
CITROEN	C4 Grand Picasso 1.6 HDi	[9HY(DV6TED4)]	10.2006-
CITROEN	C4 Grand Picasso 1.6 HDi	[9HZ(DV6TED4)]	10.2006-
CITROEN	C4 Picasso 1.6 HDi	[9HY(DV6TED4)]	02.2007-08.2013
CITROEN	C4 Picasso 1.6 HDi	[9HZ(DV6TED4)]	02.2007-08.2013
CITROEN	C5 1.6 HDi	[9HY(DV6TED4)]	09.2004-
CITROEN	C5 1.6 HDi	[9HZ(DV6TED4)]	09.2004-
CITROEN	C5 1.6 HDi 110	[9HL(DV6C)]	07.2010-
CITROEN	C5 1.6 HDi 110	[9HR(DV6C)]	07.2010-
CITROEN	C5 1.6 HDi 110	[9HZ(DV6TED4)]	02.2008-
CITROEN	C5 2.2 HDi	[4HT(DW12BTED4)]	04.2006-
CITROEN	DS3 1.4 HDi 70	[8HR(DV4C)]	04.2010-07.2015
CITROEN	DS3 1.6 HDi 110	[9HR(DV6C)]	11.2009-07.2015
CITROEN	DS3 1.6 HDi 90	[9HP(DV6DTED)]	11.2009-07.2015
CITROEN	DS4 1.6 HDi 110	[9HR(DV6C)]	04.2011-07.2015
CITROEN	DS5 1.6 HDi 110	[9HR(DV6C)]	11.2011-07.2015
CITROEN	DS5 1.6 HDi 115	[9HD(DV6C)]	06.2012-07.2015
CITROEN	Nemo 1.4 HDi	[8HS(DV4TED)]	02.2008-
CITROEN	Nemo 1.4 HDi	[8HS(DV4TED)]	04.2009-
CITROEN	Xsara Picasso 1.6 HDi	[9HY(DV6TED4)]	05.2004-
CITROEN	Xsara Picasso 1.6 HDi	[9HZ(DV6TED4)]	05.2004-

M000T22472 101329M M000T22473 96628540080 M000T22471 9.80167E+11 9.66353E+11 101329V M0T22473ZZ9 STR5339 5802ZB CST35246AS 5802Z9 5802AA 9662854080 5802EG CST35246RS 9663528880 5802Z8 M000R22471AM CST35246OS 220429 M000T22471AM M0T22472AM M0T22473AM M000T22473AM M000T22472AM M0R22471AM M0T22471AM M000T2243 CST35246GS M0T22471 M0T22472 EAA-141374 M0T22473 9801667780 28100YV020 CST35246ES M0T2243 S12MH0014A2 9645100680 MITM0T22473 6035246 M000T22473ZZ9 CST35246

101329M 101329V 6035246 96628540080 966352888001 980166778000 CST35246 CST35246AS CST35246ES CST35246GS CST35246OS CST35246RS EAA-141374 M000R22471AM M000T2243 M000T22471 M000T22471AM M000T22472AM M000T22473 M000T22473AM M000T22473ZZ9 M0R22471AM M0T2243 M0T22471 M0T22471AM M0T22472 M0T22472AM M0T22473 M0T22473AM M0T22473ZZ9 MITM0T22473 220068 220429
