Associated Numbers
19143N 19143R 25015 56029577A 56029577AA 830.914.102 91-27-3491 DRS0862 M000T38671 M0T38671 RL029577AA S-80516 UD13790SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 195 mm |
Mount Hole Center - Center (O.1) | 116 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 27.5 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | 200 2.4 | 01.2011-12.2014 | |
DODGE | Avenger 2.4 | 01.2011-12.2014 | |
LANCIA | Flavia 2.4 | [EDG] | 03.2012-12.2014 |
Reference Information
91-27-3491 56029577AA 56029577A UD13790S 25015 RL029577AA 830.914.102 19143N S-80516 DRS0862 M000T38671 19143R M0T38671Video/Publications
19143N 19143R 25015 56029577A 56029577AA 830.914.102 91-27-3491 DRS0862 M000T38671 M0T38671 RL029577AA S-80516 UD13790SAdd Your Number
